Specification
| Items | Specifications | |
|---|---|---|
| Rated voltage | DC 12V (Test voltage: 14.5V) | |
| Operating temperature range | 30°C ~ +80°C (-22°F ~ 176°F) | |
| Rated load (12V) | Lighting switch | 0.4A (Relay load) |
| Wiper switch | 0.2A (Relay load) | |
| Washer switch | 0.2A (Relay load) | |
MULTIFUNCTION SWITCH SPECIFICATIONS CHART
Scheme 1
Scheme 2
Scheme 3
Scheme 4
- Check BCM input/output specification of multifunction switch using the GDS. If the specification is abnormal, replace the head lamp or wiper switch.
- If diagnosis is required on the multifunction switch, select model and "IPM"
- Select "Input/output monitoring".
- Check the input/output condition of lamp switch or wiper switch.
- To check the DTC of the multifunction switch, select "DIAGNOSTIC TROUBLE CODES"
Scheme 5
Scheme 6
Scheme 7
- Disconnect the negative (-) battery terminal.
- Remove the steering column upper and lower shrouds (A) after removing 3 screws and connector.
- Remove the screws on top of multifunction switch.
- Remove the multifunction switch (A) after disconnecting the connector.
