Button Engine Start System: Removal & Installation Hyundai Equus II

Starter 12 illustrations ~239 words

Installation

  1. Install the connector.
  2. Install the start/stop button.

Scheme 34

Scheme 34: Component

Scheme 35

Scheme 35: Removal

Scheme 36

Scheme 36

Scheme 37

Scheme 37
  1. Disconnect the negative(-) battery terminal.
  2. Remove the glove box assembly and housing. (Refer to " «CRASH PAD»(ref-417751-S11778651202011083000000) ")
  3. Remove the connectors (A).
  4. Remove the Fob holder assembly(A) from the glove box housing.
  1. Install the fob holder assembly to the glove box housing.
  2. Install the glove box housing.

Scheme 38

Scheme 38: Component

Scheme 39

Scheme 39: Removal

Scheme 40

Scheme 40

Scheme 41

Scheme 41

Scheme 42

Scheme 42
  1. Disconnect the negative(-) battery terminal.
  2. Remove the center fascia panel (A). (Refer to " «CRASH PAD»(ref-417751-S11778651202011083000000) ")
  3. Remove the DIS head unit (A). (Refer to " «DIS SYSTEM»(ref-417775-S15808840842011083000000) ")
  4. Remove the crash pad lower panel (A).
  5. Remove the power distribution module(A) after loosening bolt and nut.
  1. Install the power distribution module.
  2. Install the crash pad lower panel.
  3. Install the DIS head unit.
  4. Install the center fascia panel.

Scheme 43

Scheme 43: PDM Diagnosis With GDS

Scheme 44

Scheme 44

Scheme 45

Scheme 45
  1. It will be able to diagnose defects of Smart key with GDS quickly. GDS can operates actuator forcefully, input/output value monitoring and self diagnosis.
  2. Select model and "IPM" menu if you want to check PDM.
  3. Select "PDM" in the menu.
  4. Select Input/output monitoring", if you want to check current data of PDM. It provides the input/output status of each module.
  5. If you want to check PDM data operation forcefully, select "Actuation test".

Input/output Current Data

NODescriptionUnit
1Load Battery VoltageV
2Abs Speed Sensor(main)Km/h
3Start Stop Button SWOFF/ON
4ACC inputOFF/ON
5IGN1 InputOFF/ON
6IGN2 InputOFF/ON
7Fob In SwitchRELEASE/INSERT
8Start Relay Monitoring Input
9SSB Ember LED OutputOFF/ON
10SSB Blue LED OutputOFF/ON
11Fob Holder Illumination OutputOFF/ON
12SSB Illumination OutputOFF/ON
13ACC Relay OutputOFF/ON
14IGN1 Relay OutputOFF/ON
15IGN2 Relay OutputOFF/ON
16Start Relay S1 OutputOFF/ON
17ESCL Battery OutputOFF/ON
18ESCL GND OutputOFF/ON
19CPU Battery VoltageV
20Engine SpeedDATA*1.0
21ACC Relay SCBOFF/ON
22IGN1 Relay SCBOFF/ON
23IGN2 Relay SCBOFF/ON
24Start Relay SCBOFF/ON
25SCC Relay OpenOFF/ON
26IGN1 Relay OpenOFF/ON
27IGN2 Relay OpenOFF/ON
28ACC Output SCBOFF/ON
29IGN1 Output SCBOFF/ON
30IGN2 Output SCBOFF/ON
31Start Output SCBOFF/ON
32ACC Output SCGOFF/ON
33IGN1 Output SCGOFF/ON
34IGN2 Output SCGOFF/ON
35Start Output SCGOFF/ON

INPUT/OUTPUT CURRENT DATA REFERENCE CHART

Actuation Test

No.Description
1SSB Ember LED
2SSB Blue LED
3Fob Holder Illumination
4SSB Illumination
5ACC Output
6ING1 Output
7ING2 Output
8Start Output

ACTUATION TEST REFERENCE CHART
