Front Back View Camera System: Overview Hyundai Equus II

Navigation System 9 illustrations ~287 words

Scheme 27

Scheme 27: Component Location
Scheme 27: Component Location

In case of applying DIS system, Front back view camera unit includes PGS (Parking Guide System) function.

In case of only applying AV & Navigation system, Front back view camera unit doesn't include PGS (Parking Guide System) function.

Scheme 28

Scheme 28: Circuit Diagram
Scheme 28: Circuit Diagram

Description

Front blind camera is a supplemental system that shows blind spot in front of the vehicle through the AV monitor.

The front blind camera will operate when you push the button and shift the transaxle into N(Neutral) or D(Drive) while driving less then 10km/h. After the vehicle stops for 4 minutes with the transaxle in N(Neutral) or D(Drive), it will bring up the previous screen.

Back view camera will activate when the backup light is ON with the ignition switch ON and the shift lever in the R position.

This system is a supplemental system that shows behind the vehicle through the AV monitor while backing-up.

WARNINGThis system is a supplementary function only. It is the responsibility of the driver or always check the inside/outside rearview mirror and the area behind the vehicle before and while backing up because there is areas that can't be seen through the camera.

Scheme 29

Scheme 29: Front Blind Camera
Scheme 29: Front Blind Camera

Scheme 30

Scheme 30
Scheme 30
  1. Remove the front bumper cover. (Refer to the " «FRONT BUMPER»(ref-417737-S37452559852011083000000) ")
  2. Remove the front blind camera (B) after removing the connector (A) and screws (4EA).

Scheme 31

Scheme 31: Back View Camera
Scheme 31: Back View Camera
  1. Remove the screws, clip and trunk lid trim in the trunk. (Refer to the " «TRUNK LID»(ref-417748-S01197328372011083000000) ")
  2. Remove the trunk lid panel.
  3. Remove the back view camera (B) after removing the connector (A) and screws (2EA).

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33: Front Back View Camera Unit
Scheme 33: Front Back View Camera Unit

Scheme 34

Scheme 34
Scheme 34

Scheme 35

Scheme 35
Scheme 35
  1. Disconnect the negative (-) battery terminal.
  2. Remove glove box housing (A). (Refer to " «CRASH PAD»(ref-417751-S11778651202011083000000) ")
  3. Disconnect the glove box housing connector (A).
  4. Remove the DIS head unit. (Refer to " «DIS SYSTEM»(ref-417775-S15808840842011083000000) ")
  5. Remove the USB interface unit.
  6. Remove the front back view camera unit (A) after removing the nuts (2EA) and connector.
