System Overview
The DIS (Driver Information System) has been designed so that it can connect to external devices (USB and iPod) and support Bluetooth. The system also interfaces with various other vehicle systems to display their statuses on screen. In addition, the screen itself is a touch screen.
Description
The AUX JACK on the center console is for customers who like to listen to external portable music players like the MP3, iPOD and etc., through the vehicle's sound system when it is linked to this jack. The customer has this added option.
In case of distortions from media connected to the AUX source, the audio unit may not be defective but the output level of the used media does not match the specification of the AUX input.
Note. Hyundai-iPod cable must be used to iPod playback. The Apple-iPod cable supplied with the player will NOT work.
Scheme 2
Scheme 3
Scheme 4
- Remove the floor console (A). (Refer to " «CONSOLE»(ref-417751-S12034632032011083000000) ")
- Disconnect the jack connector from the floor console. NOTE: Be careful not to damage jack connector when disconnecting the jack connector from the console.
- Remove the Multi media Jack (A) from the floor console.
