Specifications
| Items | Specifications | |
|---|---|---|
| Rated voltage | DC 12V | |
| Operating temperature range | 30°C ~ +80°C (-22 ~ +176°F) | |
| Rated load | Dimmer & passing switch | High: 1.0A (Relay load) Low: 1.0A (Relay load) Passing: 1.0A (Relay load) |
| Lighting switch | Lighting: 1.0A (Relay load) | |
| Turn signal & lane change switch | 6.6 ± 0.5A (Lamp load) | |
| Fog lamp switch | 1.0A (Relay load) | |
| Wiper & mist switch | Low, High: 4.0A (Motor load) Intermittent: 0.22 ± 0.05A (Relay load) Lock: Max. 28A (Motor load) Mist: 4.0A (Motor load) | |
| Washer switch | 4A (Motor load) | |
MULTIFUNCTION SWITCH SPECIFICATION
Scheme 1
| Connector name | No | Description | Connector name | No | Description |
|---|---|---|---|---|---|
| Lighting (13 pin) | 1 | Lighting switch GND | Wiper & Washer (14 Pin) | 1 | Mist switch |
| 2 | Tail lamp switch | 2 | Wiper parking | ||
| 3 | Auto light switch | 3 | Wiper low speed | ||
| 4 | Head lamp switch | 4 | |||
| 5 | Fog lamp switch base | 5 | |||
| 6 | Front fog lamp switch | 6 | |||
| 7 | 7 | ||||
| 8 | Head lamp low | 8 | Intermittent wiper switch | ||
| 9 | Head lamp high | 9 | Wiper high speed | ||
| 10 | Dimmer switch base | 10 | IGN2 (Front wiper & washer) | ||
| 11 | Turn signal left | 11 | Washer switch | ||
| 12 | Turn signal base | 12 | INT volume base | ||
| 13 | Turn signal right | 13 | INT time | ||
| 14 | |||||
CONNECTOR DESCRIPTION
