Motor Driven Power Steering: Specifications Hyundai Elantra V

Electronic Steering 7 illustrations ~373 words

Specification

Bat. VoltageIG Key ONENG. ON
Approx. 11.8 [V]~12.5 [V]Approx. 12.5 [V] ~ 14.5 [V]

VOLTAGE SPECIFICATION

Scheme 43

Scheme 43: Diagnostic Circuit Diagram

Scheme 44

Scheme 44: Monitor Scantool Data
  1. Connect scantool to Data Link Connector (DLC).
  2. Start engine and turn the headlight and the heat wire on.
  3. Monitor the "BATTERY VOLTAGE" parameter on the scantool.
  4. Maintaining ENG. RPM at 2, 500RPM (idle) over 2 minutes. Specification: less than 17 [V]
  5. Is parameter within specifications? YES Fault is intermittent and caused either by poor contact in connectors or wiring harness, or it has been repaired and EPS CM memory is not cleared yet. Thoroughly check all connectors (and connections) for looseness, bending, corrosion, contamination, deterioration, and/or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-587146-S22234295482013112200000) " procedure. Go to Next procedure. NO Go to " «W/HARNESS INSPECTION»(ref-587146-S34880292452013112200000) " procedure.
Bat. VoltageIG Key ONENG. ON
Approx. 11.8 [V] ~ 12.5 [V]Approx. 12.5 [V] ~ 14.5 [V]

VOLTAGE SPECIFICATION

Scheme 45

Scheme 45: Diagnostic Circuit Diagram

Scheme 46

Scheme 46: Monitor Scantool Data
  1. Connect scantool to Data Link Connector (DLC).
  2. Start engine and turn the headlight and the heat wire on.
  3. Monitor the "BATTERY VOLTAGE" parameter on the scantool.
  4. Maintaining ENG. RPM at 2, 500RPM (idle) over 2 minutes. Specification: more than 10 [V]
  5. Is parameter within specifications? YES Fault is intermittent and caused either by poor contact in connectors or wiring harness, or it has been repaired and EPS CM memory is not cleared yet. Thoroughly check all connectors (and connections) for looseness, bending, corrosion, contamination, deterioration, and/or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-587146-S18811972842013112200000) " procedure. Go to Next procedure. NO Go to " «W/HARNESS INSPECTION»(ref-587146-S26806765272013112200000) " procedure.
Bat. VoltageIG Key ONENG. ON
Approx. 11.8 [V] ~ 12.5 [V]Approx. 12.5 [V] ~ 14.5 [V]

VOLTAGE SPECIFICATION

Scheme 47

Scheme 47: Diagnostic Circuit Diagram

Scheme 48

Scheme 48: Monitor Scantool Data
  1. Connect scantool to Data Link Connector (DLC).
  2. Start engine and turn the headlight and the heat wire on.
  3. Monitor the "BATTERY VOLTAGE" parameter on the scantool.
  4. Maintaining ENG. RPM at 2, 500RPM (idle) over 2 minutes. Specification: less than 17 [V]
  5. Is parameter within specifications? YES Fault is intermittent and caused either by poor contact in connectors or wiring harness, or it has been repaired and EPS CM memory is not cleared yet. Thoroughly check all connectors (and connections) for looseness, bending, corrosion, contamination, deterioration, and/or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-587146-S13254359482013112200000) " procedure. Go to Next procedure. NO Go to " «W/HARNESS INSPECTION»(ref-587146-S01673900742013112200000) " procedure.
Bat. VoltageIG Key ONENG. ON
Approx. 11.8 [V] ~ 12.5 [V]Approx. 12.5 [V] ~ 14.5 [V]

VOLTAGE SPECIFICATION

Scheme 49

Scheme 49: Diagnostic Circuit Diagram
