Tightening Torques
| Item | N.m | Kgf.m |
|---|---|---|
| Ignition coil bolt | 9.8 ~ 11.8 | 1.0 ~ 1.2 |
| Spark plug | 14.7 ~ 24.5 | 1.5 ~ 2.5 |
| Condenser bolt | 9.8 ~ 11.8 | 1.0 ~ 1.2 |
| Alternator B-terminal cable nut | 9.8 ~ 14.7 | 1.0 ~ 1.5 |
| Alternator mounting bolt (M10) | 29.4 ~ 41.2 | 3.0 ~ 4.2 |
| Alternator mounting bolt (M8) | 21.6 ~ 32.4 | 2.2 ~ 3.3 |
| Alternator brace mounting bolt | 21.6 ~ 32.4 | 2.2 ~ 3.3 |
| Battery positive terminal | 7.8 ~ 9.8 | 0.8 ~ 1.0 |
| Battery negative terminal | 4.0 ~ 6.0 | 0.4 ~ 0.6 |
| Battery mounting bracket bolt | 8.8 ~ 13.7 | 0.9 ~ 1.4 |
| Battery tray mounting bolt | 8.8 ~ 13.7 | 0.9 ~ 1.4 |
| Starter B-terminal cable nut | 9.8 ~ 11.8 | 1.0 ~ 1.2 |
| Starter mounting bolt | 42.2 ~ 53.9 | 4.3 ~ 5.5 |
TIGHTENING TORQUES SPECIFICATION
| CAUTION | COLD CRANKING AMPERAGE is the amperage a battery can deliver for 30 seconds and maintain a terminal voltage of 7.2V or greater at a specified temperature. RESERVE CAPACITY RATING is amount of time a battery can deliver 25A and maintain a minimum terminal voltage of 10.5V at 26.7°C (80.1°F). |
Scheme 32
Scheme 33
