General Information - Automatic Transaxle System - A6GF1: Specifications Hyundai Elantra V

Automatic Trans 16 illustrations ~174 words

Specifications

Type: Negative Thermal Coefficient Type

Temp. [(°C) °F]Resistance (kohms)
(-40) -4048.1
(-20) -4.015.6
(0) 32.05.88
(20) 68.02.51
(40) 104.01.19
(60) 140.00.61
(80) 176.00.32
(100) 212.00.18
(120) 248.00.10
(140) 284.00.06
(150) 302.00.05

RESISTANCE SPECIFICATION

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33: Circuit Diagram
Scheme 33: Circuit Diagram

Type: Hall effect sensor

Operation condition [°C (°F)]((-)40 ~ 150)) -40 ~ 302
Air gap (mm)in.(1.2 ~ 1.8) 0.0472 ~ 0.0709
Output voltage (V)High1.18 ~ 1.68
Low0.59 ~ 0.84

SENSOR SPECIFICATION

Scheme 34

Scheme 34: Circuit Diagram
Scheme 34: Circuit Diagram

Scheme 35

Scheme 35: Signal Waveform
Scheme 35: Signal Waveform

Scheme 36

Scheme 36
Scheme 36

Type: Hall effect sensor

Operation condition [°C (°F)]((-)40 ~ 150)) -40 ~ 302
Air gap (mm)in.(1.1 ~ 1.55) 0.043 ~ 0.061
Output voltageHigh1.18 ~ 1.68
Low0.59 ~ 0.84

SENSOR SPECIFICATION

Scheme 37

Scheme 37: Circuit Diagram
Scheme 37: Circuit Diagram

Scheme 38

Scheme 38: Signal Waveform
Scheme 38: Signal Waveform

Scheme 39

Scheme 39
Scheme 39

Direct control VFS[T/CON]

Control type: Normal low type

Control Pressure kpa (kgf/cm 2 , psi)9.81 ~ 500.14 (0.1 ~ 5.1, 1.42 ~ 72.54)
Current value (mA)50 ~ 850
Internal resistance (ohms)5.1

CONTROL PRESSURE SPECIFICATION

Scheme 40

Scheme 40: Circuit Diagram
Scheme 40: Circuit Diagram

Direct control VFS[26/B]

Control type: Normal low type

Control Pressure kpa (kgf/cm 2 , psi)9.81 ~ 500.14 (0.1 ~ 5.1, 1.42 ~ 72.54)
Current value (mA)50 ~ 850
Internal resistance (ohms)5.1

CONTROL PRESSURE SPECIFICATION

Scheme 41

Scheme 41: Circuit Diagram
Scheme 41: Circuit Diagram

Direct control VFS[LINE Pressure]

Control type: Normal low type

Control Pressure kpa (kgf/cm 2 , psi)500.14 ~ 9.81 (5.1 ~ 0.1, 72.54 ~ 1.42)
Current value (mA)50 ~ 850
Internal resistance (ohms)5.1

CONTROL PRESSURE SPECIFICATION

Scheme 42

Scheme 42: Circuit Diagram
Scheme 42: Circuit Diagram

Direct control VFS[35R/C]

Control type: Normal low type

Control Pressure kpa (kgf/cm 2 , psi)500.14 ~ 9.81 (5.1 ~ 0.1, 72.54 ~ 1.42)
Current value (mA)50 ~ 850
Internal resistance (ohms)5.1

CONTROL PRESSURE SPECIFICATION

Scheme 43

Scheme 43: Circuit Diagram
Scheme 43: Circuit Diagram

Direct control VFS [35R/C]

Control type: Normal low type

Control Pressure kpa (kgf/cm 2 , psi)500.14 ~ 9.81 (5.1 ~ 0.1, 72.54 ~ 1.42)
Current value (mA)50 ~ 850
Internal resistance (ohms)5.1

CONTROL PRESSURE SPECIFICATION

Scheme 44

Scheme 44: Circuit Diagram
Scheme 44: Circuit Diagram

Direct control VFS[35R/C]

Control type: Normal low type

Control Pressure kpa (kgf/cm 2 , psi)500.14 ~ 9.81 (5.1 ~ 0.1, 72.54 ~ 1.42)
Current value (mA)50 ~ 850
Internal resistance (ohms)5.1

CONTROL PRESSURE SPECIFICATION

Scheme 45

Scheme 45: Circuit Diagram
Scheme 45: Circuit Diagram

ON/OFF Solenoid Valve (SS-A, SS-B)

Control type: Normal low type

Control pressure kpa (kgf/cm 2 , psi)490.33 (5.0, 71.12)
Internal resistance (ohms)10 ~ 11

CONTROL PRESSURE SPECIFICATION

Scheme 46

Scheme 46: Circuit Diagram
Scheme 46: Circuit Diagram

ON/OFF Solenoid Valve (SS-A, SS-B)

Control type: Normal low type

Control pressure kpa (kgf/cm 2 , psi)490.33 (5.0, 71.12)
Internal resistance (ohms)10 ~ 11

CONTROL PRESSURE SPECIFICATION

Scheme 47

Scheme 47: Circuit Diagram
Scheme 47: Circuit Diagram

Type: Combination of output signals from 4 terminals

Power supply (V)12
Output typeCombination of output signals

VOLTAGE SPECIFICATION
