Specifications
| Items | Specifications | |
|---|---|---|
| Rated voltage | DC 12V | |
| Operating temperature range | 30°C ~ +80°C (-22 ~ +176°F) | |
| Rated load | Dimmer & passing switch | High : 1A (Relay load) Low : 1A (Relay load) Passing : 1A (Relay load) |
| Lighting switch | Lighting : 1A (Relay load) | |
| Turn signal switch | 6.6 ± 0.5A (Lamp load) | |
| Wiper & mist switch | Low, High : 4.5A (Motor load) Intermittent : 0.22 ± 0.05A (Relay load) Lock : Max. 28A (Motor load) Mist : 4A (Motor load) | |
| Fog lamp switch | 1A (Relay load) | |
| Variable intermittent volume switch | Max. 25mA | |
SPECIFICATION
Scheme 1
Scheme 2
- With the multi function switch in each position, make sure that continuity exists between the terminals below. If continuity is not as specified, replace the multi-function switch
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
- With the multi function switch in each position, make sure that continuity exists between the terminals below. If continuity is not as specified, replace the multi-function switch.
Scheme 8
Scheme 9
Scheme 10
Scheme 11
Scheme 12
Scheme 13
- Disconnect the negative (-) battery terminal.
- Remove the steering column upper and lower shrouds (A) after removing 3 screws. (Refer to «STEERING COLUMN AND SHAFT»(ref-381703-S04272428352010123100000) ).
- Remove the light switch (A) by pushing the lock pin (B) after disconnecting the connector.
- Remove the wiper switch (A) by pushing the lock pin (B) after disconnecting the connector.
