IGNITION SYSTEM
| Items | Specifications |
|---|---|
| Ignition coil | |
| Type | Mold coil type |
| Primary resistance | 0.58 +/- 10% (ohms) |
| Secondary resistance | 8.8 +/- 15% (kohms) |
| Spark plugs | |
| NGK | BKR5ES-11 |
| CHAMPION | RC10YCPB4 |
| Gap | 1.0 ~ 1.1 mm (0.039 ~ 0.043 in.) |
IGNITION SYSTEM
STARTING SYSTEM
| Items | Specifications |
|---|---|
| Starter | |
| Type | Reduction drive (with planetary gear) |
| Rated voltage | 12V, 1.2KW |
| No. of pinion teeth | 8 |
| No-load characteristics | |
| Voltage | 11V |
| Amperage | 90A, Max. |
| Speed | 3,000 RPM, Min. |
| Commutator diameter | |
| Standard | 29.4 mm (1.157 in.) |
| Limit | 28.4 mm (1.118 in.) |
| Undercut depth | |
| Standard | 0.5 mm (0.02 in.) |
| Limit | 0.2 mm (0.008 in.) |
STARTING SYSTEM
CHARGING SYSTEM
| Items | Specifications |
|---|---|
| Generator | |
| Type | Battery voltage sensing |
| Rated voltage | 13.5V, 90A |
| Speed in use | 1000 ~ 18,000 RPM |
| Voltage regulator | Electronic built-in type |
| Regulator setting voltage | 14.4 +/- 0.2V |
| Temperature compensation | 10 +/- 3 mV/°C |
| Battery | |
| Type | MF60AH |
| Cold cranking amperage [at - 18°C (0°F)] | 550A |
| Reserve capacity | 92min |
| Specific gravity [at 25°C (77°F)] | 1,280 +/- 0.01 |
CHARGING SYSTEM
Note. COLD CRANKING AMPERAGE is the amperage a battery can deliver for 30 seconds and maintain a terminal voltage of 7.2V or greater at a specified temperature. REVERSE CAPACITY RATING is the amount of time a battery can deliver 25A and maintain a minimum terminal voltage of 10.5V at 26.7°C(80°F)
AUTO CRUISE CONTROL SYSTEM
| Items | Specifications |
|---|---|
| Seating error | Within +/- 1.5Km/h on level road (+/- 1MPH) |
| Vehicle speed memory variation | No variation |
| Setting time | 0.1 sec max. |
| Resuming time | 0.1 sec max. |
| Minimum operating speed | 40 +/- 2Km/h (25 +/- 1.2MPH) |
| Cancel speed range | 15 +/- 2Km/h (9 +/- 1.2MPH) |
| Maximum memorized speed | 160 +/- 2Km/h (99 +/- 1.2MPH) |
| Pulling force | 127N(13Kgf) (28.6 lb-force) |
| Main switch serial resistance value | 3.9kohms +/- 1% |
| Command switch serial resistance value | SET switch: 220ohms +/- 1% |
| RESUME switch: 910ohms +/- 1% |
AUTO CRUISE CONTROL SYSTEM
| Symptom | Suspect Area | Remedy (See) |
|---|---|---|
| Engine will not start or is hard to start (Cranks OK) | Ignition lock switch | See INSPECT IGNITION SWITCH |
| Ignition coil | See INSPECT IGNITION COIL | |
| Spark plugs | See INSPECT SPARK PLUG AND SPARK PLUG CABLE | |
| Ignition wiring disconnected or broken | See REPLACEMENT | |
| Spark plug cable | See INSPECT SPARK PLUG AND SPARK PLUG CABLE | |
| Rough idle or stalls | Ignition wiring | Inspect |
| Ignition coil | See INSPECT IGNITION COIL | |
| Spark plug cable | See INSPECT SPARK PLUG AND SPARK PLUG CABLE | |
| Engine hesitates/poor acceleration | Spark plugs and spark plug cable | See INSPECT SPARK PLUG AND SPARK PLUG CABLE |
| Ignition wiring | Inspect | |
| Poor mileage | Spark plugs and spark plugs cable | See INSPECT SPARK PLUG AND SPARK PLUG CABLE |
IGNITION SYSTEM
| Symptom | Suspect Area | Remedy (See) |
|---|---|---|
| Charging warning indicator does not light with ignition switch "ON" and engine off | Fuse blown | Check fuses |
| Light burned out | Replace light | |
| Wiring connection loose | Tighten loose connections | |
| Electronic voltage regulator | See VOLTAGE DROP TEST OF GENERATOR OUTPUT WIRE | |
| Charging warning indicator does not go out with engine running (Battery requires frequent recharging) | Drive belt loose or worn | See CHECK BATTERY TERMINALS, FUSIBLE LINK AND FUSES , BATTERY DIAGNOSTIC TEST (1) |
| Battery cables loose, corroded or worn | See ALTERNATOR BELT INSPECTION AND ADJUSTMENT | |
| Fuse blown | Check fuses | |
| Fusible link blown | Replace fusible link | |
| Electronic voltage regulator or generator | See VOLTAGE DROP TEST OF GENERATOR OUTPUT WIRE | |
| Wiring | Repair wiring | |
| Engine hesitates/poor acceleration Overcharge | Drive belt loose or worn | See CHECK BATTERY TERMINALS, FUSIBLE LINK AND FUSES , BATTERY DIAGNOSTIC TEST (1) |
| Wiring connection loose or open circuit | Tighten loose connection or repair wiring | |
| Fusible link blown | Replace fusible link | |
| Poor grounding | Repair | |
| Electronic voltage regulator or generator | See VOLTAGE DROP TEST OF GENERATOR OUTPUT WIRE | |
| Worn battery | Replace battery | |
| Electronic voltage regulator | See VOLTAGE DROP TEST OF GENERATOR OUTPUT WIRE | |
| Voltage sensing wire | Repair wire |
CHARGING SYSTEM
| Symptom | Suspect Area | Remedy (See) |
|---|---|---|
| Engine will not crank | Battery charge low | Charge or replace battery |
| Battery cables loose, corroded or worn out | Repair or replace cables | |
| Transaxle range switch (Vehicle with automatic transaxle only) | See AUTOMATIC TRANSAXLE (F4A42) | |
| Fusible link blown | Replace fusible link | |
| Starter motor faulty | See START TEST | |
| Ignition switch faulty | See INSPECT IGNITION SWITCH | |
| Engine cranks slowly | Battery charge low | Charge or replace battery |
| Battery cables loose, corroded or worn out | Repair or replace cables | |
| Starter motor | See START TEST | |
| Starter keeps running | Starter motor | See START TEST |
| Ignition switch | See INSPECT IGNITION SWITCH | |
| Starter spins but engine will not crank | Short in wiring | Repair wiring |
| Pinion gear teeth broken or starter motor | See STARTER | |
| Ring gear teeth broken | See STARTER |
STARTING SYSTEM
CRUISE CONTROL SYSTEM
Note. Before troubleshooting: Check the No. 2 (10A), No.8 (10A), No. 10 (10A) and No. 16 (15A) fuse in the under - hood fuse/relay box. Check that the horn sounds. Check the tachometer to see if it works properly.
| Symptom | Suspect Area | See |
|---|---|---|
| Cruise control cannot be set | Cruise control switch | See CRUISE CONTROL SWITCH TEST |
| Brake switch | See BRAKE SWITCH TEST | |
| A/T gear position switch | See AUTOMATIC TRANSAXLE (F4A42) | |
| Cruise control unit | See CRUISE CONTROL COMMUNICATION CIRCUIT TROUBLESHOOTING (A/T) | |
| Cruise control cannot be set and indicator light does not go on | Dimming circuit in gauge | See CRUISE CONTROL COMMUNICATION CIRCUIT TROUBLESHOOTING (A/T) |
| Cruise control unit | See CRUISE CONTROL COMMUNICATION CIRCUIT TROUBLESHOOTING (A/T) | |
| Cruise speed is noticeably higher or lower than what was set | Vehicle speed sensor | See AUTOMATIC TRANSAXLE (F4A42) |
| Cruise control unit and actuator cable deflection | See ACTUATOR CABLE ADJUSTMENT | |
| Cruise control unit | See CRUISE CONTROL COMMUNICATION CIRCUIT TROUBLESHOOTING (A/T) | |
| Excessive overshooting or undershooting when trying to set speed | Cruise control unit and actuator cable deflection | See ACTUATOR CABLE ADJUSTMENT |
| Vehicle speed sensor | See AUTOMATIC TRANSAXLE (F4A42) | |
| Cruise control unit | See CRUISE CONTROL COMMUNICATION CIRCUIT TROUBLESHOOTING (A/T) | |
| Speed fluctuation on a flat road with cruise control set | Vehicle speed sensor | See AUTOMATIC TRANSAXLE (F4A42) |
| Cruise control unit and actuator cable deflection | See ACTUATOR CABLE ADJUSTMENT | |
| Cruise control unit | See CRUISE CONTROL COMMUNICATION CIRCUIT TROUBLESHOOTING (A/T) | |
| Vehicle does not decelerate or accelerate accordingly when SET/RESUME/CANCEL button is pushed | Cruise control switch | See CRUISE CONTROL SWITCH TEST |
| Cruise control unit | See CRUISE CONTROL COMMUNICATION CIRCUIT TROUBLESHOOTING (A/T) | |
| Cruise control does not cancel when shift lever is moved to N position (A/T) | A/T gear position switch | See AUTOMATIC TRANSAXLE (F4A42) |
| Cruise control unit | See CRUISE CONTROL COMMUNICATION CIRCUIT TROUBLESHOOTING (A/T) | |
| Set speed is not cancelled when brake pedal is pushed | Brake switch | See BRAKE SWITCH TEST |
| Cruise control unit | See CRUISE CONTROL COMMUNICATION CIRCUIT TROUBLESHOOTING (A/T) | |
| Cruise control will not cancel when main switch is pushed OFF | Cruise control switch | See CRUISE CONTROL SWITCH TEST |
| Cruise control unit | See CRUISE CONTROL COMMUNICATION CIRCUIT TROUBLESHOOTING (A/T) | |
| Cruise control will not cancel when CANCEL button is pushed | Cruise control switch | See CRUISE CONTROL SWITCH TEST |
| Cruise control unit | See CRUISE CONTROL COMMUNICATION CIRCUIT TROUBLESHOOTING (A/T) | |
| Set speed will not resume when RESUME button (with main switch on, when set speed is temporarily cancelled) is depressed | Cruise control switch | See CRUISE CONTROL SWITCH TEST |
| Cruise control unit | See CRUISE CONTROL COMMUNICATION CIRCUIT TROUBLESHOOTING (A/T) | |
| The transmission shifts down slower than normal when going up a hill with the cruise control on (A/T) | Troubleshooting the cruise control communication circuit | See CRUISE CONTROL COMMUNICATION CIRCUIT TROUBLESHOOTING (A/T) |
CRUISE CONTROL SYSTEM
Scheme 25
Scheme 26
- Start the engine.
- Turn on the cruise control main switch, then drive the vehicle to speeds over 25 mph (40km/h) with the cruise control. Does the cruise control operate ? YES - Go to step 3. NO - Check the cruise control unit or cruise control actuator.
- Measure the voltage between terminal of the cruise control unit connector and ground. Is there approx. 1V? YES - Go to step 4. NO - Replace the cruise control unit.
- Measure the voltage between the No.8 terminal of the TCM connector and ground. Is there approx. 1V? NO - Repair short or open in the wire between the No.8 terminal and cruise control unit.
THE MICRO 570 ANALYZER
The MICRO 570 Analyzer provides the ability to test the charging and starting systems, including the battery, starter and generator.
| CAUTION | Because of the possibility of personal Injury, always use extreme caution and appropriate eye protection when working with batteries. |
Scheme 27
KEYPAD
The MICRO570 buttons on the key pad provide the following functions
Scheme 28
Scheme 29
Scheme 30
Scheme 31
Scheme 32
Scheme 33
- Connect the tester to the battery. Red clamp to battery positive (+) terminal. Black clamp to battery negative (-) terminal. CAUTION: Connect clamps securely. If "CHECK CONNECTION" message is displayed on the screen, reconnect clamps securely.
- The tester will ask if the battery is connected "IN A VEHICLE" or "OUT OF A VEHICLE". Make your selection by pressing the arrow buttons; then press ENTER.
- Choose either CCA or CCP and press the ENTER button. NOTE: CCA: Cold cranking amps, is an SAE specification for cranking batteries at 0°F (-18°C). CCP: Cold cranking power, is an SAE specification for Korean manufacturer's for cranking batteries at 0°F (-18°C).
- Set the CCA value displayed on the screen to the CCA value marked on the battery label by pressing up and down buttons and press ENTER.
- The tester (Micro570) displays battery test results including voltage and battery ratings. A relevant action must be taken according to the test results by referring to the battery test results as shown in «BATTERY TEST RESULTS»(ref-263270-S05669844282007090500000) . NOTE: The battery ratings (CCA) displayed on the tester must be identical to the ratings marked on the battery label.
- To conduct starter test, continuously, press ENTER.
