Wiring diagram: Body computer — Body computer circuits, without etacm Hyundai Elantra III

Components on these wiring diagrams

Click a component to highlight it on every diagram it appears on.

• Def Sw On Input Tail Lp Relay Cntl Seat Belt Sw Input Door Switch On Input
• Defogger System Exterior Lights Sys Warning Systems
• Fuse 2
• Fuse 24
• Fuse 25
• I/P-G
• I/P-H
• I/P-J
• Ignition Key Ill, Door Warning Switch
• Int Int Washer Input
• J/C
• Left Front Door Switch
• Multipurpose Check Conn
• Passenger Compartment Junction Block
• Pre- Excitation Resistor
• Tacs Control Module
• Warning Systems
