Anti-lock brake circuits for Hyundai Elantra III (2000-2003)

ABS ACTIVE MODULE ABS CONTROL MODULE (IN RIGHT FRONT CORNER OF ENGINE COMPARTMENT) ABS INDICATOR BLK WIRE BLU WIRE BRN WIRE BRN/ORG WIRE DATA LINK CONNECTOR (DLC) (PARTIAL) (ON LEFT SIDE OF DASH) ENGINE CONTROL MODULE (BEHIND LEFT SIDE OF DASH) FUSE 10 FUSE 11 FUSE 16 FUSE 2 FUSIBLE LINK (ABS 1) FUSIBLE LINK (ABS 2) GRN WIRE GRN/BLK WIRE GRN/ORG WIRE GRY WIRE GRY/ORG WIRE HOT AT ALL TIMES HOT IN ON OR START I/P-B I/P-H I/P-J INDICATOR CONTROL INSTRUMENT CLUSTER LEFT FRONT WHEEL SENSOR (ON WHEEL HUB) LEFT REAR WHEEL SENSOR (ON WHEEL HUB) NCA WIRE NOTE: ABS CONTROL MODULE CONTAINS: ABS SOLENOIDS, ABS PUMP MOTOR ORG/ WIRE PASSENGER COMPARTMENT JUNCTION BLOCK (BEHIND LEFT SIDE OF DASH) PNK WIRE RED WIRE RED/ORG WIRE RIGHT FRONT WHEEL SENSOR (ON WHEEL HUB) RIGHT REAR WHEEL SENSOR (ON WHEEL HUB) SOLID STATE STOPLIGHT SWITCH (ON BRAKE PEDAL BRACKET) TCS INDICATOR TCS SWITCH W/CRUISE CONTROL W/O CRUISE CONTROL WHEEL SPEED INPUT WHEEL SPEED INPUT GROUND ABS PUMP MOTOR WHT WIRE
