REMOVAL & INSTALLATION
| WARNING | To avoid injury from accidental air bag deployment, read and carefully follow all SERVICE PRECAUTIONS and DISABLING & ACTIVATING AIR BAG SYSTEM procedures. See AIR BAG DEACTIVATION PROCEDURES article in GENERAL INFORMATION. |
Disconnect brakelight switch electrical connector. Loosen and remove lock nut. Unscrew brakelight switch from brake pedal bracket. To install, reverse removal procedure. Adjust brakelight switch. See BRAKELIGHT SWITCH under ADJUSTMENTS.
Remove center console for access to park position/key lock switch. Disconnect park position/key lock switch electrical connector. Remove switch assembly from gearshift lever. (Scheme 75) To install, reverse removal procedure.
Scheme 75
Scheme 75: Removal & Installation
Remove center console for access to shift lock solenoid. Disconnect shift lock solenoid electrical connector. Remove solenoid assembly from gearshift lever. (Scheme 75) To install, reverse removal procedure.
Shift Interlock System Wiring Diagram (1997 Accent). Scheme 76
Scheme 76: Shift Interlock System Wiring Diagram (1997 Accent)
Shift Interlock System Wiring Diagram (1998 Accent). Scheme 77
Scheme 77: Shift Interlock System Wiring Diagram (1998 Accent)
Shift Interlock System Wiring Diagram (1999 Accent). Scheme 78
Scheme 78: Shift Interlock System Wiring Diagram (1999 Accent)
Shift Interlock System Wiring Diagram (1997 Elantra). Scheme 79
Scheme 79: Shift Interlock System Wiring Diagram (1997 Elantra)
Shift Interlock System Wiring Diagram (1998 Elantra). Scheme 80
Scheme 80: Shift Interlock System Wiring Diagram (1998 Elantra)
Shift Interlock System Wiring Diagram (1999 Elantra). Scheme 81
Scheme 81: Shift Interlock System Wiring Diagram (1999 Elantra)
Shift Interlock System Wiring Diagram (1997 Sonata). Scheme 82
Scheme 82: Shift Interlock System Wiring Diagram (1997 Sonata)
Shift Interlock System Wiring Diagram (1998-99 Sonata). Scheme 83
Scheme 83: Shift Interlock System Wiring Diagram (1998-99 Sonata)
Shift Interlock System Wiring Diagram (1997 Tiburon). Scheme 84
Scheme 84: Shift Interlock System Wiring Diagram (1997 Tiburon)
Shift Interlock System Wiring Diagram (1998 Tiburon). Scheme 85
Scheme 85: Shift Interlock System Wiring Diagram (1998 Tiburon)
Shift Interlock System Wiring Diagram (1999 Tiburon). Scheme 86
Scheme 86: Shift Interlock System Wiring Diagram (1999 Tiburon)
