Maintenance Information: Overview Hyundai Elantra II

Procedures 2 illustrations ~560 words

MODEL IDENTIFICATION

Note. For scheduled maintenance intervals and the related fluid capacities, fluid specifications and labor times for major service intervals, see SCHEDULED SERVICES article in this section. Warranty information and specifications for fluid capacities, lubrication specifications, wheel and tire size, and battery type are covered in this article.

Fuse & Circuit Breaker Identification

  1. 1 - 15 Amp (Early Production), 10 Amp (Late Production) - A/C Relay
  2. 2 - 10 Amp - Hazard Lights
  3. 3 - 15 Amp - Stoplights, Cruise Control
  4. 4 - 10 Amp - Radio, Transmission Control Unit, Power Antenna
  5. 5 - 10 Amp (Early Production), 15 Amp (Late Production) - Power Locks, Trunk Lid Opener
  6. 6 - 10 Amp (Early Production), 15 Amp (Late Production) - Interior Light, Map Light Cluster
  7. 7 - 20 Amp - Timer & Alarm Control Unit (T.A.C.U.)
  8. 8 - 15 Amp (Early Production), 10 Amp (Late Production) - Ignition Key Warning, Clock
  9. 9 - 15 Amp (Early Production), 10 Amp (Late Production) - Back-Up Lights, Turn/Hazard Relay
  10. 10 - 10 Amp - Clock, Cluster T.A.C.U., A/T Key Lock Unit
  11. 11 - 15 Amp - T.A.C.U., Wiper Motor, Washer Motor
  12. 12 - 10 Amp - Sunroof, Relay (Headlight/Blower/Power Window), Dash Cluster
  13. 13 - 10 Amp (Early Production), 15 Amp (Late Production) - Blower Actuator, T.C.U. Inhibitor Switch, Cruise Control
  14. 14 - 10 Amp - Radio, Power Mirror, Taillight Relay, A/T Key Lock Unit
  15. 15 - 10 Amp (Early Production), 15 Amp (Late Production) - Cigarette Lighter
  16. 16 - 10 Amp - Power Window, Cluster, A/C Switch, Taillights (Left)
  17. 17 - 10 Amp - Taillights (Right)
  18. 18 - 15 Amp (Early Production), 10 Amp (Late Production) - A/C Switch
  19. 19 - 10 Amp - Seatbelt Release System, Power Steering

Scheme 1

Scheme 1: FUSIBLE LINK & RELAY IDENTIFICATION - 1992
Scheme 1: FUSIBLE LINK & RELAY IDENTIFICATION - 1992

Fusible Link & Relay Identification

WARNINGAlways disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician.
  1. A - 30 Amp (Pink) - Ignition Power Source
  2. B - 20 Amp (Blue) - MPI
  3. C - 30 Amp (Pink) - Power Window
  4. D - 50 Amp (Red) - Battery Power Source
  5. E - 40 Amp (Green) - Headlamps
  6. F - 30 Amp (Pink) - Radiator Fan Controls
  7. 1 - Not Used
  8. 2 - 20 Amp - Condenser Fan Controls
  9. 3 - 10 Amp - Horns
  10. 4 - 10 Amp - Headlamp Indicator
  11. 5 - Not Used
  12. 6 - 20 Amp - Headlamps
  13. 7 - 30 Amp - Blower Controls

Scheme 2

Scheme 2: FUSE PANEL IDENTIFICATION - 1993-94
Scheme 2: FUSE PANEL IDENTIFICATION - 1993-94
  1. 1 - 10 Amp - A/C Compressor Controls
  2. 2 - 10 Amp - Hazard Lights
  3. 3 - 15 Amp - Stoplights, Cruise Control
  4. 4 - 10 Amp - Radio, TCM, Power Antenna
  5. 5 - 15 Amp - Power Locks, Trunk Lid Opener
  6. 6 - 15 Amp - Sunroof, Courtesy Lights
  7. 7 - 20 Amp - Rear Window Defogger
  8. 8 - 10 Amp - Cluster, Interior Lights, Clock
  9. 9 - 10 Amp - Back-Up Lights, Turn Signal Lights
  10. 10 - 10 Amp - Clock, Cluster
  11. 11 - 15 Amp - Wiper Motor, Washer Motor
  12. 12 - 10 Amp - Sunroof, Relay (Headlight/Blower/Power Window), Dash Cluster
  13. 13 - 15 Amp - T.C.U. Inhibitor Switch, Auto Cruise
  14. 14 - 10 Amp - Radio, Power Mirror
  15. 15 - 15 Amp - Cigarette Lighter
  16. 16 - 10 Amp - LH Taillights
  17. 17 - 10 Amp - RH Taillights
  18. 18 - 10 Amp - A/C Controls
  19. 19 - 10 Amp - Passive Seatbelt System

FUSE PANEL IDENTIFICATION - 1995-96

Fuse panel identification is not available from manufacturer.
