Engine Controls - Specifications Hyundai Elantra I

Specifications 5 illustrations ~196 words

INTRODUCTION

Use this article to quickly find specifications related to servicing and on-vehicle adjustments. This is a quick reference article to use when you are familiar with an adjustment procedure and only need a specification.

SERVICE INTERVALS & SPECIFICATIONS

ComponentInterval (Miles)
Air Filter30,000
Automatic Transaxle Fluid30,000
Belts60,000
Brake Fluid30,000
Coolant30,000
Fuel Filter60,000
Fuel & Vapor Hoses(1) 30,000
Oil & Filter7500
Spark Plugs(2) 30,000
Timing Belt(2) 60,000
(1) Scoupe only. (2) Every 70,000 on Sonata 3.0L.
(1)Scoupe only.
(2)Every 70,000 on Sonata 3.0L.

REPLACEMENT INTERVALS

Application(1) Deflection In. (mm)
Elantra "V" Belt.35-.45 (9.0-11.5)
Excel & Scoupe
A/C Belt.32-.40 (8.1-10.2)
Alternator Belt.28-.32 (7.1-8.1)
Sonata 2.0L
A/C Belt.32 (8.1)
Alternator Belt.35-.41 (9.0-10.4)
P/S Belt.28-.39 (7.1-9.9)
Sonata 3.0L
A/C Belt.17-.21 (4.3-5.3)
Alternator & P/S Belt.28-.39 (7.1-9.9)
(1) Deflection with 22-lb. (10 kg) pressure applied midway on belt run.
(1)Deflection with 22-lb. (10 kg) pressure applied midway on belt run.

BELT ADJUSTMENT

CAPACITIES

ApplicationAmp Hr. Rating
Elantra, Excel, Scoupe & Sonata 2.0L48 Or 60
Sonata 3.0L55 Or 68

BATTERY SPECIFICATIONS

ApplicationQuantity
Automatic Transaxle (Dexron-II)
Elantra, Excel & Scoupe6.4 Qts. (6.1L)
Sonata
2.0L6.4 Qts. (6.1L)
3.0L6.1 Qts. (5.8L)
Cooling System (Includes Heater & Reserve Tank)
Elantra5.4 Qts. (5.0L)
Excel & Scoupe5.6 Qts. (5.3L)
Sonata
2.0L7.7 Qts. (7.3L)
3.0L9.0 Qts. (8.5L)
Crankcase (Includes Filter)
Elantra4.6 Qts. (4.4L)
Excel & Scoupe3.6 Qts. (3.4L)
Sonata
2.0L3.9 Qts. (3.7L)
3.0L4.2 Qts. (4.0L)
Manual Transaxle (SAE 75W-85/API GL-4)
Elantra KM1761.9 Qts. (1.8L)
Excel & Scoupe
KM2011.9 Qts. (1.8L)
KM2001.8 Qts. (1.7L)
Sonata 2.0L1.9 Qts. (1.8L)
Power Steering (Dexron-II)1.0 Qt. (.9L)

FLUID CAPACITIES

IDLE SPEED & MIXTURE

Note. Idle speed and mixture are computer controlled.

FAST IDLE SPEED

Note. Fast idle speed is computer controlled.

THROTTLE POSITION SENSOR (TPS)

ApplicationVolts At Idle
All Models.48-.52

TPS VOLTAGE SPECIFICATIONS

ENGINE COMPRESSION

ApplicationSpecification
Compression Ratio
1.5L9.4:1
1.6L9.2:1
2.0L9.0:1
3.0L8.9:1
Compression Pressure
1.5L192 psi (13.5 kg/cm 2 )
1.6L171 psi (12.0 kg/cm 2 )
2.0L171 psi (12.0 kg/cm 2 )
3.0L173 psi (12.2 kg/cm 2 )
Maximum Variation Between Cylinders All Models14 psi (1.0 kg/cm 2 )

COMPRESSION SPECIFICATIONS

VALVE CLEARANCE

Note. Elantra and Sonata are equipped with hydraulic lash adjusters; no adjustments are required.

ApplicationLifter Type
1.5LMechanical
1.6LHydraulic
2.0LHydraulic
3.0LHydraulic

VALVE LIFTER APPLICATION

Application(1) In. (mm)
Intake.006 (.15)
Exhaust.010 (.25)
(1) Adjust valves with engine at normal operating temperature.
(1)Adjust valves with engine at normal operating temperature.

VALVE CLEARANCE SPECIFICATIONS - 1.5L

IGNITION COIL

ApplicationPrimarySecondary
Elantra.77-.9510,300-13,900
Excel & Scoupe.72-.8810,300-13,900
Sonata
2.0L.77-.9510,300-13,900
3.0L.72-.8810,300-13,900

IGNITION COIL RESISTANCE Ohms @ 68°F (20°C)

HIGH TENSION WIRE RESISTANCE

ApplicationOhms
Excel
No. 110.1
No. 211.8
No. 311.8
No. 414.2
Coil WireInformation not available.
Elantra
No. 15.8
No. 28.4
No. 310.6
No. 49.7
Coil WireInformation not available.
Scoupe
No. 19.8
No. 211.7
No. 311.0
No. 412.6
Coil Wire2.7
Sonata
2.0L
No. 15.8
No. 28.4
No. 310.6
No. 49.7
Coil WireInformation not available.
3.0L
No. 17.4
No. 25.4
No. 39.1
No. 46.9
No. 510.2
No. 68.0
Coil Wire5.8

HIGH TENSION WIRE RESISTANCE

SPARK PLUGS

ApplicationNumber
1.5L, 1.6L & 2.0L
NGKBPR6ES-11/BUR6EA-11
ChampionRN9YC4
3.0L
NDP16PR11
NGKPGR5A 11

SPARK PLUG TYPE

ApplicationGap: In. (mm)Torque: Ft. Lbs. (N.m)
All Models.039-.043 (1.0-1.1)15-21 (20-28)

SPARK PLUG SPECIFICATIONS

FIRING ORDER & TIMING MARKS

Note. For firing order (Scheme 1)- (Scheme 3). To locate timing marks (Scheme 4)or (Scheme 5).

Firing Order & Distributor Rotation (1.5L). Scheme 1

Scheme 1: Firing Order & Distributor Rotation (1.5L)
Scheme 1: Firing Order & Distributor Rotation (1.5L)

Firing Order (1.6L & 2.0L). Scheme 2

Scheme 2: Firing Order (1.6L & 2.0L)
Scheme 2: Firing Order (1.6L & 2.0L)

Firing Order & Distributor Rotation (3.0L). Scheme 3

Scheme 3: Firing Order & Distributor Rotation (3.0L)
Scheme 3: Firing Order & Distributor Rotation (3.0L)

IGNITION TIMING

Application(2) Basic(3) Actual
1.5L3-7 @ 600-80010 @ 600-800
1.6L3-7 @ 650-8508 @ 650-850
2.0L3-7 @ 650-8508 @ 650-850
3.0L (4)3-7 @ 600-80015 @ 650-850
(1) Degrees BTDC @ RPM. (2) With ignition timing adjustment connector grounded. (3) With ignition timing adjustment connector ungrounded. (4) DO NOT adjust basic timing with Mutli-Use Tester (MUT) connected.
(1)Degrees BTDC @ RPM.
(2)With ignition timing adjustment connector grounded.
(3)With ignition timing adjustment connector ungrounded.
(4)DO NOT adjust basic timing with Mutli-Use Tester (MUT) connected.

IGNITION TIMING (1)

Scheme 4

Scheme 4: Ignition Timing Marks (Elantra, Excel & Scoupe)
Scheme 4: Ignition Timing Marks (Elantra, Excel & Scoupe)

Scheme 5

Scheme 5: Ignition Timing Marks (Sonata)
Scheme 5: Ignition Timing Marks (Sonata)

FUEL PUMP

Engine ApplicationAt Idle W/ Vacuum psi (kg/cm 2 )At Idle W/O Vacuum psi (kg/cm 2 )
All Models39 (2.8)46-49 (3.3-3.5)

REGULATED FUEL PRESSURE

INJECTOR RESISTANCE

ApplicationOhms
All Models13-16

INJECTOR RESISTANCE
