Multifunction Switch: Overview Hyundai Azera I

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

1. Multi function switch operates head lamps and wiper through LIN communication with BCM.
2. Check BCM input/output specification of multi function switch using the scan tool. If the specification is abnormal, replace the head lamp or wiper switch.
3. If you make a diagnosis of multi function switch with the scan tool, select model and "BCM".
4. Select "Current data" and check the Input/Output condition of BCM.

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

1. Disconnect the negative (-) battery terminal.
2. Remove the steering column upper and lower shrouds (A) after removing 3 screws.
3. Remove the multi function switch after loosening 2 screws and disconnecting connector. (In case of multi function switch assembly replacement)
4. Remove the light switch (A) after loosening 2 screws.
5. Remove the wiper switch (A) after disconnecting the connector and loosening 2 screws.
6. Installation is the reverse of removal.
