Fuses & Relays: Overview Hyundai Azera I

Fuses & Circuit Breakers 5 illustrations

Scheme 1

Scheme 1: COMPONENT LOCATION

Scheme 2

Scheme 2

Scheme 3

Scheme 3: FUSE/RELAY BOX

Note. * Use designated fuses only.

FUSIBLE LINKAMPERAGECIRCUIT PROTECTED
ABS-140AABS Control Module, Multipurpose Check Connector
ABS-220AABS Control Module, Multipurpose Check Connector
I/P (B+)140AFuse (FR P/Seat, RR P/Seat, T/LID, T/SIG, TILT, Pedal, RR Curtain
RR HTD40ADefogger Relay
BLOWER40ABlower Relay
P/WDW40AFuse (P/WDW LH, PWDW RH)
IGN-240AIgnition Switch (IG2 Start), Start Relay
ECU RLY30AEngine Control Relay
I/P (B+)230AFuse (KEY SOL., ECS/RR FOG), Power Connector
IGN-130AIgnition Switch (ACC, IG1)
ALT150AFusible Link (ABS1, ABS2, RR HTD, BLOWER)

IDENTIFYING RELAY BOX FUSIBLE LINKS (ENGINE COMPARTMENT)

FUSEAMPERAGECIRCUIT PROTECTED
1HORN15AHorn Relay
2TAIL20ATail Lamp Relay
3ECU10APCM
4IG110ANot Used
5DRL15ABurglar Alarm Horn Relay
6FR FOG15AFront Fog Lamp Relay
7A/CON10AA/C Relay
8F/ PUMP20AFuel Pump Relay
9DiodeNot Used
10ATM20AATM Control Relay
11STOP15AStop Lamp Switch
12HID LO RH15AHID Relay (Only For HID LP)
13SUN ROOF15AOverhead Console Lamp
14H/LP Washer20ANot Used
15H/LP HI20AHead Lamp Relay (HIGH)
16ECV(B+)10APCM
17SNSR310AA/C Relay Cooling Fan Relay Injectors #1, -6
18SNSR115AImmobilizer Control Module MAF Sensor PCM Oil Control Valve#1, -2 Variable Intake Manifold Valve
19SNSR215AO2 Sensor #1, 2, 3, 4
20B/UP10ABack-up Lamp Switch Stop Lamp Switch Transaxle Range Switch Vehicle Speed Sensor
21IGN COIL20AIGN Coil #1 -6, Condenser
22ECU10APCM
23H/LP LO HID LO LH20AHead Lamp Relay (LOW)
24ABS10AABS Control Module ESP Module Multipurpose Check Connector

IDENTIFYING RELAY BOX FUSES (ENGINE COMPARTMENT)

DESCRIPTION

The ICM is united with many kinds of relays and installed below the body control module.

Relay box (Assist compartment).

Scheme 4

Scheme 4: DESCRIPTION

Scheme 5

Scheme 5
