SPECIFICATION

AUDIO

Item		Specification
Model		AM/FM/CD/MP3 (M445)	AM/FM/XM/CD/MP3 (M445S)	AM/FM/XM/Cassette/CD/MP3 (M455)	AM/FM/XM/CD/MP3 (M455S)	AM/FM/Cassette/6CDC/MP3 (M465)	AM/FM/XM/6CDC/MP3 (M465S)
Power supply		DC 14.4V
Rated output		Max 43W x4 (Power IC)		3.2Vrms
Antenna		80PF 75ohms
Tuning type		PLL synthesized type
Frequency range/Channel space	FM	87.5~107.9 MHz/200KHz
Frequency range/Channel space	AM	530~1710 kHz (9KHz)
* XM : Satellite Radio

AUDIO SPECIFICATION

SPEAKER

Item		M445	M445S	M455	M455S	M465	M465S
Input Power (W)	Front	Max 40	Max 40	Max 40	Max 40	Max 40	Max 40
	Rear	Max 40	Max 40	Max 40	Max 40	Max 40	Max 40
	Tweeter	Max 40	Max 40	Max 20	Max 20	Max 20	Max 20
	Center			Max 32	Max 32	Max 32	Max 32
	Sub woofer			Max 64	Max 64	Max 64	Max 64
	Package tray surround			Max 32	Max 32	Max 32	Max 32
Speaker Impedance (ohms)	Front	4 ± 0.6	4 ± 0.6	2 ± 0.4	2 ± 0.4	2 ± 0.4	2 ± 0.4
	Rear	4 ± 0.6	4 ± 0.6	2 ± 0.4	2 ± 0.4	2 ± 0.4	2 ± 0.4
	Tweeter	4 ± 0.6	4 ± 0.6	4 ± 0.8	4 ± 0.8	4 ± 0.8	4 ± 0.8
	Center			2.15 ± 0.25	2.15 ± 0.25	2.15 ± 0.25	2.15 ± 0.25
	Sub woofer			1.35 ± 0.25	1.35 ± 0.25	1.35 ± 0.25	1.35 ± 0.25
	Package tray surround			2.15 ± 0.25	2.15 ± 0.25	2.15 ± 0.25	2.15 ± 0.25
Speaker Number		6	6	10	10	10	10

SPEAKER SPECIFICATION

EXTERNAL AMPLIFIER

Item	Audio
Power supply	DC 14.4V
Output power	55W x 11 ch

EXTERNAL AMPLIFIER SPECIFICATION

SET TOP BOX (FOR SDARS)

Item	Specification
Tuning Frequency Range	2.33875 GHz (REF)
Input impedance	50ohms
Audio output	1.0 Vrms
Antenna output voltage	DC 5.0 V
Operating voltage	DC 14.4 V

SET TOP BOX SPECIFICATION (FOR SDARS)

SDARS ROOF ANTENNA

Item	Specification
Rated voltage	DC 4.9V
Consumption current	40mA to 65mA (+25°C)
Frequency range	2332.5MHz - 2345 MHz
Polarization	Satellite : Left handed circular Terrestrial : Vertical
* SDARS : Satellite Digital Audio Radio Service

SDARS ROOF ANTENNA SPECIFICATION

Scheme 1

Scheme 1: AM/FM/CD/MP3 (M445)

Scheme 2

Scheme 2: AM/FM/CASSETTE/CD/MP3 (M455)

Scheme 3

Scheme 3: AM/FM/CASSETTE/6CDC/MP3 (M465)

Scheme 4

Scheme 4: AM/FM/XM/CD/MP3 (M445S)

Scheme 5

Scheme 5: AM/FM/XM/CD/MP3 (M455S)

Scheme 6

Scheme 6: AM/FM/XM/CD/MP3 (M465S)

Scheme 7

Scheme 7: SET TOP BOX

Scheme 8

Scheme 8: CIRCUIT DIAGRAM

Scheme 9

Scheme 9: TAPE HEAD AND CAPSTAN CLEANING

To obtain optimum performance, clean the head, and capstan as often as necessary, depending on frequency of use and tape cleanness.
To clean the tape head and capstan, use a cotton swab dipped in ordinary rubbing an alcohol. Wipe the head and capstan.

Scheme 10

Scheme 10: REPLACEMENT

Scheme 11

Disconnect the negative (-) battery terminal.
Remove the crash pad center garnish. (Refer to the «CRASH PAD»(ref-287152-S26701805032008060600000) ).
Remove the center facia panel (A) after loosening the screws. Avoid damaging retaining dips.
Remove the connectors of digital clock and hazard switch.
Remove the mounting screws then remove the audio unit (B).
Installation is the reverse of removal.

Scheme 12

Scheme 12: INSPECTION

Troubleshooting for Speaker Basic inspection of speaker after verifying that the speaker mounting screws is removed and the wiring connector is connected precisely to remove vibration transmitted from body trims and surrounding parts. Case Troubleshooting Inspection/Remedy No. Case Inspection/Remedy 1 Trembling sound 1) Before replacing the speaker, inspect that the mounting screw is installed normally. 2) After re-installing the speaker, verify that no trembling sound is hard. 3) When hearing a trembling sound again, replace the speaker with new one. 2 Noise 1) Check if the wiring connector is connected normally. If not, reconnect the wiring connector 2) In case of radio static, check if there is a noise from cassette. 3) When a noise is heard on turning radio, cassette and CD on, replace the speaker with new one. NOTE: In case there is only radio static, this causes from poor radio reception. Thus the speaker needs no repair and replacement. 3 Poor working Inspection of the wiring connection between the battery and the speaker 1) Before replacing the speaker, inspect the wiring connection between the battery and the speaker is normal. 2) Check the supplying power to the speaker and the resistance, then inspect the sound quality. Specified impedance: 2 ~ 4ohms 3) If the speaker works poorly, replace it with new one.

CAUTION

During dealing of speaker Do not damage the speaker with impact as like a drop and a throw. Be careful not to cover water and oil over the speaker. Caution during dealing of speaker because the material of diaphragm is paper which is easy to torn by impact and external force. When modifying audio system as customer please, this does electric damage to speaker. And, in this case the speakers are not covered by the manufacture's warranty.

Scheme 13

Scheme 13: FRONT SPEAKER

Remove the front door trim panel (Refer to the «FRONT DOOR»(ref-287165-S41953107162008060600000) ).
Remove the front speaker (A) after removing 4 rivets.
Installation is the reverse of removal.

Scheme 14

Scheme 14: REAR SPEAKER

Remove the rear door trim panel (Refer to the «REAR DOOR»(ref-287165-S00927168622008060600000) ).
Remove the rear speaker (A) after removing 4 rivets.
Installation is the reverse of removal.

Scheme 15

Scheme 15: TWEETER SPEAKER

Remove the front door trim panel (Refer to the «FRONT DOOR»(ref-287165-S41953107162008060600000) ).
Remove the tweeter speaker (A) after loosening 2 screws and disconnecting the connector.
Installation is the reverse of removal.

Scheme 16

Scheme 16: WOOFER SPEAKER

Remove the rear seat. (Refer to the «REAR SEAT»(/hyundai/azera/i-2005-2011/remont/seats/#seat) )
Remove the rear package tray. (Refer to the «PACKAGE TRAY»(ref-287152-S00320177932008060600000) )
Remove the woofer speaker (A) after removing 4 bolts.
Installation is the reverse of removal.

Scheme 17

Scheme 17: EXTERNAL AMPLIFIER

Remove the right luggage side trim.
Remove the external amplifier (B) from the quarter inner panel (A) after removing 3 nuts.
Installation is the reverse of removal.

Scheme 18

Scheme 18: FRONT CENTER SPEAKER

Remove the center speaker (A) after front center speaker grill.
Installation is the reverse of removal.

Scheme 19

Scheme 19: SET TOP BOX (FOR SDARS)

Remove the right luggage side trim. (Refer to the «TRUNK TRIM»(ref-287152-S40409194632008060600000) )
Remove the set top box(A) after loosening 2 bolts and disconnecting the cable and connector.
Installation is the reverse of removal.

Scheme 20

Scheme 20: REAR PACKAGE TRAY SPEAKER

Remove the rear seat. (Refer to the «REAR SEAT»(/hyundai/azera/i-2005-2011/remont/seats/#seat) ).
Remove the rear package tray. (Refer to the «PACKAGE TRAY»(ref-287152-S00320177932008060600000) ).
Remove the rear package tray speaker(A) after loosening the. 2 screws and disconnecting the connector.
Installation is the reverse of removal.

Scheme 21

Scheme 21: SDARS ROOF ANTENNA

Remove the rear headlining.
Remove the SDARS roof antenna from the roof inner panel after loosening the mounting nut(A) and disconnecting the cable(B).
Installation is the reverse of removal.

Scheme 22

Scheme 22: GLASS ANTENNA TEST

Scheme 23

Wrap aluminum foil (A) around the tip of the tester probe (B) as shown.
Touch one tester probe to the glass antenna terminal (A) hear, and move the other tester probe along the antenna wires to check that continuity exists.
