Hyundai Avante VI facelift (2018-2020) indicator switch sensor Wiring diagram
This page shows the only wiring diagram for the component.indicator switch sensor, which is found in the car Hyundai Avante VI facelift (2018-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram indicator switch sensor (1 of 1)
A/V, NAVIGATION HEAD UNIT
ADA
AUDIO
BLK WIRE
BLU WIRE
CTRL GND
ELECTROCHROMIC MIRROR
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
I/P-E
I/P-F
INDICATOR SWITCH SENSOR
INPUT
JOINT CONNECTOR URA
KEYPAD
KEYPAD GND
KEYPAD SIG
KEYPAD SIGNAL
LEAK CURRENT AUTO CUT DEVICE
MEMORY 1 FUSE
MEMORY POWER
MODULE 5 FUSE
MTS (+)
ON/ BACKUP SIGNAL
ORG/ WIRE
PCB
PHONE
RED WIRE
REMOTE +
SMART JUNCTION BLOCK
SOS
SOUND SYSTEMS
STEERING
UVO
W/ NAVIGATION
W/O NAVIGATION
YEL WIRE
Go to component -> Electrochromic mirror circuit, w/o home link -> INDICATOR SWITCH SENSOR
