Hyundai Avante VI facelift (2018–2020) wiring diagrams

List of systems:

Automatic a/c circuit Manual a/c circuit

Anti-lock brakes circuit Autonomous emergency brake circuit

Forced entry circuit Immobilizer circuit, w/o smart key system Immobilizer circuit, w/ smart key system

Body control module circuit, ad Body control module circuit, ada Ips control module circuit, ad Ips control module circuit, ada

Computer data lines circuit

Cooling fan circuit

Cruise control circuit

Defoggers circuit, w/ auto defogger Defoggers circuit, w/o auto defogger

Electronic power steering circuit

Wiring diagram engine performance 1.4l turbo

Wiring diagram engine performance 1.6l turbo

Wiring diagram engine performance 2.0l, a/t Wiring diagram engine performance 2.0l, ivt

Backup lamps circuit Exterior lamps circuit

Ground distribution circuit, ad Ground distribution circuit, ada

Autolamps circuit Headlamps circuit

Horn circuit

Instrument cluster circuit, ada w/ conventional cluster Instrument cluster circuit, ada w/ supervision Instrument cluster circuit, ad w/ conventional cluster Instrument cluster circuit, ad w/ supervision

Courtesy lamps circuit Instrument illumination circuit

Driver"s memory seat circuit Memory mirrors circuit

Blind spot information system circuit, ad Blind spot information system circuit, ada Lane keeping assist circuit Navigation circuit, w/ amplifier Navigation circuit, w/o amplifier Parking assistant circuit

Power distribution circuit, ad Power distribution circuit, ada

Power door locks circuit

Electrochromic mirror circuit, w/ home link & mts Electrochromic mirror circuit, w/ home link w/o mts Electrochromic mirror circuit, w/o home link Power mirrors circuit

Front heated seats circuit, ad Front heated seats circuit, ada Heated steering wheel circuit Power seats circuit Rear heated seats circuit

Power top/sunroof circuit

Power windows circuit, w/ ims Power windows circuit, w/o ims w/ auto up/down power windows Power windows circuit, w/o ims w/o auto up/down power windows

Radio circuit, ada w/o navigation display & compact Radio circuit, ada w/o navigation & display w/ compact Radio circuit, ad w/o navigation & display Radio circuit, w/ navigation & amplifier Radio circuit, w/ navigation w/o amplifier Radio circuit, w/o navigation w/ display & amplifier Radio circuit, w/o navigation w/ display w/o amplifier

1.4l turbo, shift interlock circuit

1.6l turbo, shift interlock circuit

2.0l, shift interlock circuit

1.4l turbo, charging circuit 1.4l turbo, starting circuit, w/o smart key 1.4l turbo, starting circuit, w/ smart key

1.6l turbo, charging circuit 1.6l turbo, starting circuit, w/o smart key 1.6l turbo, starting circuit, w/ smart key

2.0l, charging circuit 2.0l, starting circuit, w/o smart key 2.0l, starting circuit, w/ smart key

Supplemental restraints circuit

1.4l turbo, transmission circuit

1.6l turbo, transmission circuit

2.0l, transmission circuit, a/t 2.0l, transmission circuit, ivt

Trunk release circuit

Chime circuit Tire pressure monitoring circuit

Wiper/washer circuit
