Specification
| Items | Specifications |
|---|---|
| Rated voltage | DC 12 V |
| Operating temperature range | 30 ~ +80 °C (-22 ~ +176 °F) |
| Rated load | |
| Dimmer & passing switch | High : 120 W (Lamp load) Low : 110 W (Lamp load) Passing : 120 W (Lamp load) |
| Lighting switch | Lighting : 21 W (Lamp load) |
| Turn signal & lane change switch | 69 W (Lamp load) |
| Wiper & mist switch | Low, High : 5.0A (Motor load) Intermittent : 0.07 ± 0.05A (Relay load) Lock : Max. 25A (Motor load) Mist: 5A (Motor load) |
| Washer switch | 5A (Motor load) |
| Rear wiper & washer switch (3 doors) | Rear wiper : 3.5A (Motor load) Rear washer : 5A (Motor load) |
MULTIFUNCTION SWITCH SPECIFICATIONS CHART
Scheme 1
Scheme 2
Scheme 3
Scheme 4
- Disconnect the negative (-) battery terminal.
- Remove the steering column upper and lower shrouds (A) after removing 3 screws.
- Remove the light switch by pushing the lock pin (B) after disconnecting the connector (A).
- Remove the wiper switch by pushing the lock pin (B) after disconnecting the connector (A).
- Installation is the reverse of removal.
