General Information: Overview Hyundai Accent III

Oem General Information 7 illustrations ~1293 words

Scheme 5

Scheme 5: Identification Number Locations
Scheme 5: Identification Number Locations

Scheme 6

Scheme 6: Vehicle Identification Number
Scheme 6: Vehicle Identification Number
  1. World Manufacturer Identifier (WMI) KMF : Commercial vehicle (Van) KMH : Passenger vehicle or MPV (Multipurpose Passenger Vehicle)/SUV (Sports Utility Vehicle)/RV (Recreational Vehicle) KMJ : Van KM8 : MPV/SUV/RV (For U.S.A, Canada, Mexico)
  2. Vehicle line C : ACCENT
  3. Model & Series L : Low grade (L) M : Middle-Low grade (GL) N : Middle grade (GLS, JSL, TAX)
  4. Body/Cabin type, Gross Vehicle Weight Rating KMF (Commercial vehicle / Van) Except U.S.A, Canada, Mexico, Gulf Cooperation Council, China X : Standard Cabin / Semi-Bonnet Y : Double Cabin / Bonnet Z : Super Cabin / Box For U.S.A, Canada, Mexico, Gulf Cooperation Council, China 3 : Standard Cabin Class-E 4x2 / Semi-Bonnet Class-E 4x2 4 : Standard Cabin Class-E 4x4 / Semi-Bonnet Class-E 4x4 5 : Standard Cabin Class-F 4x2 / Semi-Bonnet Class-F 4x2 6 : Standard Cabin Class-F 4x4 / Semi-Bonnet Class-F 4x4 7 : Double Cabin Class-E 4x2 / Bonnet Class-E 4x2 8 : Double Cabin Class-E 4x4 / Bonnet Class-E 4x4 9 : Double Cabin Class-F 4x2 / Bonnet Class-F 4x2 0 : Double Cabin Class-F 4x4 / Bonnet Class-F 4x4 A : Super Cabin Class-E 4x2 / Box Class-E 4x2 B : Super Cabin Class-E 4x4 / Box Class-E 4x4 C : Super Cabin Class-F 4x2 / Box Class-F 4x2 D : Super Cabin Class-F 4x4 / Box Class-F 4x4 KMH 1 : Limousine 2 : Sedan - 2 door 3 : Sedan - 3 door 4 : Sedan - 4 door 5 : Sedan - 5 door 6 : Coupe 7 : Convertible 8 : Wagon 9 : Commercial Van 0 : Pick-Up KMJ 1 : Box 2 : Bonnet 3 : Semi-Bonnet KM8 1 : Wagon 4x2 Class-A 2 : Wagon 4x2 Class-B 3 : Wagon 4x2 Class-C 4 : Wagon 4x2 Class-D 5 : Wagon 4x2 Class-E 6 : Wagon 4x2 Class-F 7 : Wagon 4x2 Class-G A : Wagon 4x4 Class-A B : Wagon 4x4 Class-B C : Wagon 4x4 Class-C D : Wagon 4x4 Class-D E : Wagon 4x4 Class-E F : Wagon 4x4 Class-F G : Wagon 4x4 Class-G
  5. Restraint system, Brake system KMH, KM8 Except U.S.A, Canada, Mexico 0 : Both side - None 1 : Both side - Active belt 2 : Both side - Passive belt For U.S.A, Canada, Mexico AIR BAG REFERENCE CHART Code Seat belt Front air bag Knee air bag Side air bag Curtain air bag Driver's Passenger's Driver's Passenger's 1st row 2nd row 3rd row 1st row 2nd row 3rd row A o o o x x o x x o o x B o o o x x x x x x x x C o o o x x o x x o o o D o o o x x o o x o o x E o o x x x x x x x x x F o o o x x o x x x x x N o x x x x x x x x x x KMJ Except U.S.A, Canada, Mexico 7 : Hydraulic brake system 8 : Pneumatic brake system 9 : Mixed brake system For U.S.A, Canada, Mexico X : Hydraulic brake system Y : Pneumatic brake system Z : Mixed brake system KMF Except U.S.A, Canada, Mexico 7 : Hydraulic brake system 8 : Pneumatic brake system 9 : Mixed brake system For U.S.A, Canada, Mexico RESTRAINT SYSTEM REFERENCE CHART Code Restraint system Brake system Seat belt Front air bag Knee air bag Side air bag Curtain air bag Hydraulic Pneumatic Mixed Driver's Passenger's Driver's Passenger's 1st row 2nd row 3rd row 1st row 2nd row 3rd row X o x x x x x x x x x x o - - V o o x x x x x x x x x o - - W o o o x x x x x x x x o
  6. Engine type C: Gasoline engine 1.6
  7. Check digit or Driver's side & Transmission Except U.S.A, Canada, Mexico, Gulf Cooperation Council, China, Yemen A : LHD & MT B : LHD & AT C : LHD & MT+Transfer D : LHD & AT+Transfer E : LHD & CVT L : RHD & MT M : RHD & AT N : RHD & MT+Transfer S : RHD & AT+Transfer T : RHD & CVT For U.S.A, Canada, Mexico, Gulf Cooperation Council, China, Yemen Check digit : 0 ~ 9, x
  8. Production year A : 2010, B : 2011, C : 2012, D : 2013 ...
  9. Plant of production A : Asan (Korea) C : Cheonju (Korea) U : Ulsan (Korea)
  10. Vehicle production sequence number 000001 ~ 999999 Paint Code PAINT CODE CHART Code Color NW NOBLE WHITE EB EBONY BLACK HL HIPHOP RED 5S SPACE SILVER 2B SKY BLUE 9G GOLD BEIGE 3E BLUE ONYX 3W SHEER YELLOW 2M MIDNIGHT GRAY 8N LEAF GREEN 5R RUBY RED

Scheme 7

Scheme 7: Engine Number
Scheme 7: Engine Number
  1. Engine fuel G = Gasoline
  2. Engine range 4 = 4 cycle 4 cylinder
  3. Engine development order E = ALPHA Engine
  4. Engine capacity D = 1,599 cc
  5. Production year 9 : 2009, A : 2010, B : 2011, C : 2012, D : 2013...
  6. Engine production sequence number 000001 ~ 999999

Scheme 8

Scheme 8: Manual
Scheme 8: Manual
  1. Model R = M5CF1 P = M5CF2
  2. Production year 9 : 2009, A : 2010, B : 2011, C : 2012, D : 2013...
  3. Gear ratio (Tooth number) < Differential drive gear tooth number / Output shaft gear tooth number> 1873 = 73/18 = 4.056
  4. Transaxle production sequence number 000001 ~ 999999

Scheme 9

Scheme 9: Automatic
Scheme 9: Automatic
  1. Model T = A4AF3
  2. Production year 9 : 2009, A : 2010, B : 2011, C : 2012, D : 2013...
  3. Gear ratio N = 4.041
  4. Detailed chassification BR = 1.6 CVVT
  5. Spare
  6. Transaxle production sequence number 000001 ~ 999999

Scheme 10

Scheme 10: Warning/Caution Label Locations
Scheme 10: Warning/Caution Label Locations

Scheme 11

Scheme 11: Battery Caution Label Description
Scheme 11: Battery Caution Label Description
  1. Keep lighted cigarettes and all other flames or sparks away from the battery.
  2. Wear eye protection when charging or working near a battery. Always provide ventilation when working in an enclosed space. When lifting a plastic-cased battery, excessive pressure on acid to leak resulting in personal injury. Lift with a battery carrier or with your hands on opposite corners. Never attempt to change the battery when the battery cables are connected. The electrical ignition system works with high voltage. Never touch these components with the engine running or the ignition switched on.
  3. Keep batteries out of the reach of children because batteries contain highly corrosive SULFURIC ACID. Do not allow battery acid to contact your skin, eyes, clothing or paint finish.
  4. If any electrolyte gets into your eyes, flush your eyes with clean water for at least 15 minutes and get immediate medical attention. If possible, continue to apply water with a sponge or cloth until medical attention is received. If electrolyte gets on your skin, thoroughly wash the contacted area. If you feel a pain or a burning sensation, get medical attention immediately.
  5. Always read the following instructions carefully when handing a battery.
  6. Hydrogen, which is a highly combustible gas, is always presents in battery cells and may explode if ignited.
  7. An improperly disposed battery can be harmful to the environment and human health. Always confirm local regulations for battery disposal.

Handling And Storage The Battery

Battery ItselfBatteries should be stored in cool, dry (27 degrees Celsius) places and out of direct sunlight. MF batteries are tightly sealed to prevent acid leakage. However, tilting the battery to an angle of 45 degrees can cause acid to leak through the vents on the sides. Therefore, batteries should always be stored in their upright positions. Prevent placing any aqueous or solid (i.e. conductors) bodies on top of the battery. It is extremely dangerous to use tools, such as hammers, on the battery terminals when connecting cables to the mounted battery.
Battery on VehicleWhen storing the vehicle for long periods of time, make sure to remove the memory fuse at junction box to prevent natural discharging. Also, run the engine for battery charging within 1 month if the memory fuse wasn't removed from the start of vehicle storing. If the memory fuse was removed, run the engine for battery charging within 3 months from the start of vehicle storing.

BATTERY HANDLING AND STORAGE CHART

Note. After reconnecting or recharging a discharged battery, the ESP OFF indicator may illuminate. In this case, turn the handle half way to the left and right whilst the ignition switch is in the ON position. Then, restart the engine after the ignition is OFF. The ESP OFF indicator may turn OFF. If the ESP OFF indicator does not turn OFF, have the system checked referring to DTC. (Refer to the ABS (ANTI-LOCK BRAKE SYSTEM) DIAGNOSIS (MGH-40) .)
