Contents Wiring diagrams Section: Entertainment Systems All sections

Audio: Other Hyundai Accent III

Entertainment Systems 17 illustrations ~599 words

Speaker

ItemSpecification
ModelFrontRearTweeter
Input powerMax 40 WMax 40 WMax 40 W
Impedance4 ± 0.6 ohms4 ± 0.6 ohms4 ± 0.6 ohms

SPEAKER SPECIFICATION

Scheme 18

Scheme 18: Component Location

Scheme 19

Scheme 19: Component

Scheme 20

Scheme 20

Scheme 21

Scheme 21

Scheme 22

Scheme 22

Scheme 23

Scheme 23: Replacement

Scheme 24

Scheme 24
  1. Disconnect the negative (-) battery terminal.
  2. Remove the center facia upper panel (A).
  3. Remove the connectors of digital clock and hazard switch (B).
  4. Remove the mounting screws then remove the audio unit (A).
  5. Installation is the reverse of removal.

Scheme 25

Scheme 25: Front Speaker
  1. Remove the front door trim panel. (Refer to " «FRONT DOOR»(ref-380305-S41206922062010121800000) ")
  2. Remove the front speaker (A) after removing 4 screws.
  3. Installation is the reverse of removal.

Scheme 26

Scheme 26: Rear Speaker (3 Doors)
  1. Remove the rear door trim panel. (Refer to " «REAR DOOR»(ref-380305-S29108864602010121800000) ")
  2. Remove the rear speaker (A) after removing 3 screws.
  3. Installation is the reverse of removal.

Scheme 27

Scheme 27: Rear Speaker (4 Doors)
  1. Remove the rear seat. (Refer to " «REAR SEAT»(ref-380303-S23694004052010121800000) ")
  2. Remove the rear package tray. (Refer to " «REAR SEAT»(ref-380303-S23694004052010121800000) ")
  3. Remove the rear speaker (A) after removing 4 bolts.
  4. Installation is the reverse of removal.

Scheme 28

Scheme 28: Tweeter Speaker
  1. Remove the front door trim panel. (Refer to " «FRONT DOOR»(ref-380305-S41206922062010121800000) ")
  2. Remove the tweeter speaker after disconnecting the connector (A).
  3. Installation is the reverse of removal.

Scheme 29

Scheme 29: Inspection

Scheme 30

Scheme 30
  1. Troubleshooting for Speaker Basic inspection of speaker Inspect the sound from speaker after verifying that the speaker mounting screws is removed and the wiring connector is connected precisely to remove vibration transmitted from body trims and surrounding parts. Case Troubleshooting SPEAKER TROUBLESHOOTING CHART No. Case Inspection/Remedy 1 Trembling sound Before replacing the speaker, inspect that the mounting screw is installed normally. After re-installing the speaker, verify that no trembling sound is heard. When hearing a trembling sound again, replace the speaker with new one. 2 Noise Check if the wiring connector is connected normally. If not, reconnect the wiring connector. In case of radio static, check if there is a noise from cassette. When a noise is heard on turning radio, cassette and CD on, replace the speaker with new one. NOTE: In case there is only radio static, this causes from poor radio reception. Thus the speaker needs no repair and replacement. 3 Poor working Inspection of the wiring connection between the battery and the speaker Before replacing the speaker, inspect the wiring connection between the battery and the speaker is normal. Check the supplying power to the speaker and the resistance, then inspect the sound quality. Specified impedance : 2 ~ 4 ohms 3. If the speaker works poorly, replace it with new one. CAUTION: During dealing of speaker Do not damage the speaker with impact as like a drop and a throw. Be careful not to cover water and oil over the speaker. Caution during dealing of speaker because the material of diaphragm is paper which is easy to be torn by impact and external force. When modifying audio system as customer pleases, this does electric damage to speaker. And, in this case the speakers are not covered by the manufacturer's warranty.

Scheme 31

Scheme 31: Replacement
  1. Remove the rear roof trim. (Refer to " «ROOF TRIM»(ref-380300-S00881965842010121800000) ")
  2. Disconnect the 1P connector (A) and antenna jack (B) from the roof antenna.
  3. Remove the roof antenna after removing a nut.
  4. Installation is the reverse of removal.

Scheme 32

Scheme 32: Antenna Cable

Scheme 33

Scheme 33

Scheme 34

Scheme 34
  1. Remove the antenna jack from the audio unit and antenna.
  2. Check for continuity between the center poles of antenna cable.
  3. Check for continuity between the outer poles of antenna cable. There should be continuity.
  4. If there is no continuity, replace the antenna cable.
  5. Check for continuity between the center pole (A) and outer pole (B) of antenna cable. There should be no continuity.
  6. If there is continuity, replace the antenna cable.
