Replacement Of Component Parts
When replacing the system component parts, supply the following amount of oil to the component parts to be installed.
| Component parts to be installed | Amount of Oil |
|---|---|
| Evaporator | 50 cc (1.70 fl.oz) |
| Condenser | 60 cc (2.04 fl.oz) |
| Refrigerant line (One piece) | 10 cc (0.34 fl.oz) |
OIL REFERENCE CHART
For compressor replacement, subtract the volume of oil drained from the removed compressor from the specified volume, and drain the calculated volume of oil from the new compressor
The specified volume - volume of removed compressor = volume to drain from the new compressor.
Note. Even if no oil is drained from the removed compressor, don't drain more than 50 cc from new compressor.
Scheme 52
Replacement
- Discharge refrigerant from refrigeration system (Refer to «REFRIGERANT RECOVERY»(ref-380330-S30406824212010121800000) ).
- Replace faulty tube or hose. CAUTION: Cap the open fittings immediately to keep moisture or dirt out of the system.
- Tighten joint of bolt or nut to specified torque. CAUTION: Connections should not be torque tighter than the specified torque. TIGHTENING TORQUE SPECIFICATION Part tightened N.m Kgf.m lbf.ft Condenser x Discharge hose 8 ~ 12 0.8 ~ 1.2 5.8 ~ 8.7 Condenser x Liquid tube Compressor x Discharge hose Compressor x Suction hose Expansion valve x Evaporator
- Evacuate air in refrigeration system and charge system with refrigerant (Refer to «SYSTEM CHARGING»(ref-380330-S09179966232010121800000) ). Specified amount: 500 ± 25 g
- Inspect for leakage of refrigerant. Using a gas leak detector, check for leakage of refrigerant (Refer to «REFRIGERANT LEAK TEST»(ref-380330-S33353504302010121800000) ).
- Inspect A/C operation.
