Timing Chain Hyundai Accent II facelift

Mechanical 7 illustrations ~363 words

Check the bushing and plate of timing chain for wear. Replace if wear is severe.

Scheme 112

Scheme 112: TIMING CHAIN
Scheme 112: TIMING CHAIN

Scheme 113

Scheme 113: REASSEMBLY
Scheme 113: REASSEMBLY

Scheme 114

Scheme 114
Scheme 114

Scheme 115

Scheme 115
Scheme 115

Scheme 116

Scheme 116
Scheme 116

Scheme 117

Scheme 117
Scheme 117
  1. Install the HLA.
  2. Align the camshaft timing chain with intake timing chain sprocket and exhaust timing chain sprocket as shown.
  3. Install the camshaft after lubricating the camshaft journals with engine oil.
  4. Install the bearing caps. The markings on the caps are for intake/exhaust identification. I: Intake camshaft E: Exhaust camshaft
  5. Tighten the bearing caps to the specified torque in two or three steps as shown. Tightening torque Bearing cap bolt: 12 ~ 14 Nm (120 ~ 140 kg.cm, 9 ~ 10 lb.ft)
  6. Using the special tool, camshaft oil seal installer (09221-21000), press fit the camshaft oil seal. Be sure to apply engine oil to the oil seal lip. Insert the oil seal along the camshaft front end and install by driving the installer with a hammer until the oil seal is fully seated.
  7. Install the camshaft sprocket bolts to the specified torque. Tightening torque Camshaft sprocket bolt: 80 ~ 100 N.m (800 ~ 1000 kg.cm, 59 ~ 74 lb.ft)
  8. Align the camshaft sprocket and crankshaft sprocket timing marks. Place the piston in the No. 1 cylinder to top dead center on the compression stroke. Refer to «TIMING BELT»(ref-158647-S20357225672005031600000) .
  9. Install the cylinder head cover. Tightening torque Cylinder head cover bolts: 8 ~ 10 N.m (80 ~ 100 kg.cm, 6 ~ 7 lb.ft)
  10. Install the spark plug cables, ignition coil assembly and cylinder head center cover.
  11. Install the timing belt and then tighten the timing belt tensioner pulley.
  12. Install the timing belt cover. Tightening torque Timing belt cover: 8 ~ 10 N.m (80 ~ 100 kg.cm, 6 ~ 7 lb.ft)

Scheme 118

Scheme 118: COMPONENTS
Scheme 118: COMPONENTS

DISASSEMBLY

  1. Remove the following: Timing belt. Refer to «TIMING BELT»(ref-158647-S20357225672005031600000) . Front case. Flywheel. Refer to «FLY WHEEL»(ref-158647-S30975975802005031600000) . Cylinder head assembly. Refer to «CYLINDER HEAD»(ref-158647-S12031417232005031600000) . Oil pan.
  2. Remove the rear plate and the rear oil seal.
  3. Remove the connecting rod caps.
  4. Remove the main bearing caps and remove the crankshaft.
  5. Remove the crankshaft position sensor wheel. CAUTION: Mark the main bearing caps to permit reassembly in the original position and direction.
