SPECIFICATIONS

COIL SPRING

Item	Specification
Type	Oil Type/Gas Type
Stroke mm (in.)	161 (6.3)
Damping Force at Piston Speed 0.3 m/s	Standard	Sporty Suspension
Expansion N (kg)	550 +/- 90 (55 +/- 9)	1090 +/- 160 (109 +/- 6)
Compression N (kg)	260 +/- 60 (26 +/- 6)	490 +/- 100 (49 +/- 10)

SHOCK ABSORBER

Scheme 1: SERVICE STANDARD

Items	N.m	Kgf.cm
Castle nut	220 -- 260	2200 -- 2600
Strut upper installation nut	20 -- 30	200 -- 300
Strut assembly to knuckle	75 -- 90	750 -- 900
Front strut mounting self locking nut	60 -- 70	600 -- 700
Lower arm ball joint to knuckle	60 -- 72	600 -- 720
Lower arm/lower arm bracket mounting bolt	95 -- 120	950 -- 1200
Tie rod end ball joint to knuckle	15 -- 34	150 -- 340
Rear roll stopper to sub-frame bolt	30 -- 40	300 -- 400
Rear roll stopper mounting nut	45 -- 60	450 -- 600
Rear strut mounting self locking nut	45 -- 50	450 -- 500
Rear stabilizer link to stabilizer bar	35 -- 45	350 -- 450
Rear stabilizer bar bracket bolt	17 -- 26	170 -- 260
Rear suspsension arm (A, B) to axle carrier	130 -- 150	1300 -- 1500
Rear suspension arm (A) to body frame	100 -- 120	1000 -- 1200
Rear suspension arm (B) to body frame	80 -- 100	800 -- 1000
Trailing arm to axle carrier nut	130 -- 150	1300 -- 1500
Trailing arm to bracket nut	100 -- 120	1000 -- 1200
Trailing bracket to body frame	40 -- 50	400 -- 500

Torque Specifications

CAUTION

Replace the self-locking nuts with new ones after removal.

Scheme 2: LUBRICANTS

Scheme 3: SPECIAL TOOLS

Scheme 6: TROUBLESHOOTING

Scheme 7: COMPONENTS

Scheme 8: REMOVAL

Remove the front wheel.
Detach the brake hose bracket from the strut assembly. NOTE: Do not pry or force the components excessively.
Remove the strut upper mounting nuts (3).
Remove the strut lower knuckle mounting bolts (2).
Remove the strut assembly.
Installation is the reverse of removal.
