SPECIFICATIONS
| Item | Specification |
|---|---|
| Manual steering | |
| Shaft and joint type | Collapsible, cross joints (two joints used) |
| Steering gear type | Rack and pinion |
| Rack stroke | 134 mm (lock to lock : 3.87 turns) |
| Power steering | |
| Shaft and joint type | Collapsible, cross joints, tilt column with pop-up |
| Steering gear type | Rack and pinion |
| Rack stroke | 134 mm (lock to lock : 2.93 turns) |
| Oil pump type | Vane type |
| Oil pump displacement | 9.6 cm 3 /rev. (0.59 in 3 /rev.) |
| Oil pump pressure switch operating pressure | 1.5-2.0 MPa (15-20 kg/cm 2 , 213-284 psi) |
General Specifications
Scheme 1
TIGHTENING TORQUE
| Item | Nm | Kg.cm |
|---|---|---|
| Steering wheel lock nut | 35 -- 45 | 350 -- 450 |
| Steering column and shaft assembly mounting bracket | 13 -- 18 | 130 -- 180 |
| Steering shaft and joint | 15 -- 20 | 150 -- 200 |
| Pinion gear and joint | 15 -- 20 | 150 -- 200 |
| Dust cover mounting bolt | 4 -- 6 | 40 -- 60 |
| Gear box mounting bolt | 60 -- 80 | 600 -- 800 |
| Tie rod end lock nut | 50 -- 55 | 500 -- 550 |
| Tie rod ball joint slotted nut | 16 -- 34 | 160 -- 340 |
| Rack yoke plug nut | 50 -- 70 | 500 -- 700 |
| Tie rod to rack | 80 -- 100 | 800 -- 1000 |
| Power Steering Only | ||
| Valve body housing to rack housing assembly | 20 -- 30 | 200 -- 300 |
| Pressure and return tube mounting clip | 8 -- 12 | 80 -- 120 |
| Pressure and return tube to gear box | 12 -- 18 | 120 -- 180 |
| Pinion and return valve assembly to self -- locking nut | 20 -- 30 | 200 -- 300 |
| End plug | 50 -- 70 | 500 -- 700 |
| Oil pump mounting bracket bolt | 20 -- 27 | 200 -- 270 |
| Oil pump adjusting bolt | 25 -- 33 | 250 -- 330 |
| Pressure hose mounting bolt (to oil pump) | 55 -- 65 | 550 -- 650 |
| Oil reservoir mounting bolt | 9 -- 14 | 90 -- 140 |
| Suction hose mounting clamp (to oil pump suction connector) | 3 -- 5 | 30 -- 50 |
| Oil cooler tube mounting bolt | 4 -- 6 | 40 -- 60 |
Torque Specifications
Scheme 2
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
Note. A slight "grinding noise" may be heard immediately after the engine is started in extremely cold whether conditions (below-20°C): This is due to power steering fluid characteristics in extreme cold conditions and is not an indication of malfunction.
Scheme 9
- Start the engine with the steering wheel in the straight ahead position.
- Measure the play at the circumference of the steering wheel. Standard value Steering wheel free play : 0-30 mm (0-1.1 in.)
- If the play exceeds the standard value, inspect the connection between the steering shaft and steering linkage.
Scheme 10
- Place the front wheel on a turning radius gauge and measure the steering angle. Standard value Wheel angle (Unladen state) Inner wheel : °3737' +/- 1°30' Outer wheel : 31°51'
- If the measured value is not within the standard value, adjust the toe and inspect again.
Scheme 11
Scheme 12
- Disconnect the tie rod and knuckle by using the special tool.
- Move the ball joint stud in a circular motion several times to check for looseness.
- Mount the nuts on the ball joint, and then measure the ball joint starting torque. Standard value 0.5-2.5 N.m (5-25 kg.cm, 0.36-1.78 lb.ft)
- If the starting torque exceeds the upper limit of the standard value, replace the tie rod end.
- Even if the starting torque is below the lower limit of the standard value, check the play of the ball joint and replace if necessary.
Scheme 13
- Position the vehicle on a level surface and place the steering wheel in the straight ahead position.
- Increase the engine speed to 1000 +/- 100 RPM. NOTE: After checking, reset the engine speed to the standard value (idling speed).
- Measure the turning force with a spring scale by turning the steering wheel clockwise and counterclockwise one and a half turns. Standard value Stationary steering effort: 34.3N (3.5 kg, 7.8 lbs)
- Check that there is no sudden change of force while turning the steering wheel.
- If the stationary steering effort is excessive, check and adjust the following points.
- Damage or cracks on the dust cover and tie rod end ball joint.
- Pinion preload of the steering gear box and starting torque of the tie rod end ball joint.
- Starting torque of the ball joint.
