Audio System: Overview Hyundai Accent II

Scheme 1

Scheme 2

There are six areas where a problem can occur: wiring harness, the radio, the cassette tape deck, the CD player, the speaker, and antenna. Troubleshooting enables you to confine the problem to a particular area.

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

1. RADIO
2. TAPE

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

1. CD WILL NOT BE ACCEPTED
2. NO SOUND
3. CD SOUND SKIPS Sound sometimes skips when parking. Sound sometimes skips when driving. (Stop vehicle, and check it.) (Check by using a CD which is free of scratches, dirt or other damage.)
4. SOUND QUALITY IS POOR
5. CD WILL NOT EJECT
6. NO SOUND FROM ONE SPEAKER

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

Scheme 25

1. Disconnect the negative battery terminal.
2. Remove the glove box.
3. Disconnect the heater control cables under the glove box and lower crash pad.
4. Loosen the screws and remove the center fascia panel.
5. Remove the audio mounting screws (4EA) and the audio system.
6. Installation is the reverse of removal.
