SPECIFICATIONS
| COMPONENTS | FUNCTION | REMARKS |
|---|---|---|
| Crankcase Emission System | HC reduction | |
| Positive Crankcase Ventilation (PCV) | Variable flow rate type | |
| Evaporative Emission System | HC reduction | |
| Evaporative emission canister | ||
| EVAP canister Purge Solenoid Valve | Duty control solenoid valve | |
| Exhaust Emission System | ||
| MFI system (Air-fuel mixtrue control device) | CO, HC, NOx reduction | Heated oxygen sensor |
| Three-way catalytic converter | CO, HC, NOx reduction | Feedback type Monolithic type |
| MFI : Multiport Fuel Injection | ||
| EVAP : Evaporative Emission | ||
General Specifications
Scheme 3
Scheme 4
Scheme 5
Scheme 6
Scheme 7
Scheme 8
Scheme 9
Scheme 10
- Disconnect the ventilation hose from the positive crankcase ventilation (PCV) valve. Remove the PCV valve from the rocker cover and reconnect it to the ventilation hose.
- Run the engine at idle. Put a finger on the open end of the PCV valve to verify that the intake manifold vacuum can be felt. NOTE: The plunger inside the PCV valve will move back and forth.
- If the vacuum is not felt, clean the PCV valve and ventilation hose in cleaning solvent or replace if necessary.
Scheme 11
- Remove the PCV valve.
- Insert a thin stick into the PCV valve from the threaded side to check that the plunger moves.
- If the plunger does not move, the PCV valve is clogged. Clean it or replace.
