Wipers and Washers: Specifications Hummer H3 I

Wiper/washer Systems 10 illustrations ~106 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Front Wiper Arm Shaft Nut21 N.m15 lb ft
Front Wiper Motor Bolts12 N.m9 lb ft
Rear Wiper Arm Nut9 N.m80 lb in
Rear Wiper Motor Bolts10 N.m89 lb in
Washer Solvent Reservoir Nuts10 N.m89 lb in
Wiper Motor Transmission Bolts10 N.m89 lb in

Fastener Tightening Specifications

Scheme 1

Scheme 1: Wiper/Washer Schematics
Scheme 1: Wiper/Washer Schematics

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4: Wiper/Washer Component Views
Scheme 4: Wiper/Washer Component Views
CalloutComponent Name
1Rear Window Washer Fluid Pump
2Windshield Washer Fluid Pump
3Body Harness
4Windshield Wiper/Washer Module
5Windshield Wiper Motor

Scheme 5

Scheme 5
Scheme 5
CalloutComponent Name
1Headlamp Switch
2Instrument Panel Cluster (IPC)
3Hazard Switch
4Accessory Switch
5Radio
6Ambient Light Sensor
7Inflatable Restraint I/P Module
8HVAC Control Module
9Auxiliary Power Outlets - Front
10Rear Window Wiper/Washer Switch
11Inflatable Restraint Steering Wheel Module
12Turn Signal/Multifunction Switch

Scheme 6

Scheme 6
Scheme 6
CalloutComponent Name
1Door Lock Actuator - Endgate
2Rear Window Wiper Motor
3Rear Window Defogger Connector
4Rear Window Defogger Connector
5Rear Window Defogger
6Rear Window Wiper/Washer Module
7C901 CHMSL Jumper Harness to Endgate Harness
8C450 Body Harness to Endgate Harness

Scheme 7

Scheme 7: Rear Window Washer Fluid Pump (LHD)
Scheme 7: Rear Window Washer Fluid Pump (LHD)
Connector Part Information OEM: 15326801 Service: 15306156 Description: 2-Way F GT 150 Series Sealed (BK)
Terminal Part Information Terminal/Tray: 12191818/8 Core/Insulation Crimp: See Terminal Kit Release Tool/Test Probe: See Terminal Kit

Rear Window Washer Pump Connector Parts Information

PinWire ColorCircuit No.Function
AD-GN392Rear Window Washer Switch Signal
BYE343Accessory Voltage

Rear Window Washer Fluid Pump (LHD) Connector Terminal Identification

Scheme 8

Scheme 8: Rear Window Washer Fluid Pump (RHD)
Scheme 8: Rear Window Washer Fluid Pump (RHD)
Connector Part Information OEM: 12020599 Service: 12102664 Description: 2-Way F Metri-Pack 280 Series (BK)
Terminal Part Information Terminal/Tray: 12191818/8 Core/Insulation Crimp: See Terminal Kit Release Tool/Test Probe: See Terminal Kit

Rear Window Washer Fluid Pump Connector Parts Information

PinWire ColorCircuit No.Function
AD-GN392Rear Window Washer Switch Signal
BYE343Accessory Voltage

Rear Window Washer Fluid Pump (RHD) Connector Terminal Identification

Scheme 9

Scheme 9: Rear Window Wiper Motor
Scheme 9: Rear Window Wiper Motor
Connector Part Information OEM: 1300-3111 Service: 88988645 Description: 5-Way F 090 Series (WH)
Terminal Part Information Pins: 1, 5 Terminal/Tray: 8240-4892/22 Core/Insulation Crimp: 2/4 Release Tool/Test Probe: 15315247/J-35616-18 (BK) Pins: 3-4 Terminal/Tray: 8240-4882/22 Core/Insulation Crimp: E/C Release Tool/Test Probe: 15315247/J-35616-18 (BK)

Rear Window Wiper Motor Connector Parts Information

PinWire ColorCircuit No.Function
1YE143Accessory Voltage
2D-GN392Rear Window Washer Switch Signal
3WH393Rear Window Wiper Delay 1 Signal
4GY391Rear Window Wiper Delay 2 Signal
5BK1450Ground

Rear Window Wiper Motor) Connector Terminal Identification

Scheme 10

Scheme 10: Rear Window Wiper/Washer Switch
Scheme 10: Rear Window Wiper/Washer Switch
Connector Part Information OEM: 15332141 Service: 88986249 Description: 6-Way F GT 150 Series (BK)
Terminal Part Information Terminal/Tray: 12191811/3 Core/Insulation Crimp: See Terminal Kit Release Tool/Test Probe: See Terminal Kit

Rear Window Wiper/Washer Switch Connector Parts Information

PinWire ColorCircuit No.Function
ABK2050Ground
BYE343Accessory Voltage
CWH393Rear Window Wiper Delay 1 Signal
DGY8Instrument Panel Lamps Dimmer Switch Signal
EGY391Rear Window Wiper Delay 2 Signal
FD-GN392Rear Window Washer Switch Signal

Rear Window Wiper/Washer Switch) Connector Terminal Identification
