Sunroof: Specifications — Hummer H3 I (2005-2010)

Sunroof: Specifications Hummer H3 I

Fastener Tightening Specifications

Application	Specification
Application	Metric	English
Sunroof Sunshade Handle Screws	2 N.m	18 lb in
Sunroof Air Deflector	3 N.m	27 lb in
Sunroof Drain Weeper	2 N.m	18 lb in
Sunroof Module Retaining Bolts	9 N.m	80 lb in
Sunroof Module Retaining Nuts	9 N.m	80 lb in
Sunroof Motor Bolts	6 N.m	53 lb in
Sunroof Window	4 N.m	35 lb in
Sunshade Panel Rubber Stoppers	3 N.m	27 lb in

Fastener Tightening Specifications

Scheme 1: Sunroof Schematics

Scheme 2: Sunroof Component Views

Callout	Component Name
1	Sunroof Motor
2	C330 Sunroof Jumper Harness to Body Harness
3	Sunroof Switch
4	C335 Sunroof Jumper Harness to Body Harness
5	Garage Door Opener

Scheme 3: Sunroof Motor

Connector Part Information OEM: 6240-5196 Service: 15201885 Description: 10-Way F 090 MT Series (NA)
Terminal Part Information Pins: 5, 7 Terminal/Tray: 8240-4942/22 Core/Insulation Crimp: 2/1 Release Tool/Test Probe: 15315247/J-35616-18 (BK) Pins: 8-10 Terminal/Tray: 8240-4882/22 Core/Insulation Crimp: E/C Release Tool/Test Probe: 15315247/J-35616-18 (BK)

Sunroof Motor Connector Parts Information

Pin	Wire Color	Circuit No.	Function
1-4			Not Used
5	OG	2140	Battery Positive Voltage
6			Not Used
7	BK	850	Ground
8	YE	243	Accessory Voltage
9	OG	110	Sunroof Switch Open Signal
10	BN	100	Sunroof Switch Close Signal

Sunroof Motor Connector Terminal Identification

Scheme 4: Sunroof Switch

Connector Part Information OEM: 12191825 Service: 15306048 Description: 8-Way F GT 280 Series (BN)
Terminal Part Information Terminal/Tray: 15304711/8 Core/Insulation Crimp: E/A Release Tool/Test Probe: 15315247/J-35616-4A (PU)

Sunroof Switch Connector Parts Information

Pin	Wire Color	Circuit No.	Function
A	BK	850	Ground
B	GY	8	Instrument Panel Lamps Dimmer Switch Signal
C	BK	850	Ground
D-E			Not Used
F	BN	100	Sunroof Switch Close Signal
G	OG	110	Sunroof Switch Open Signal
H			Not Used

Sunroof Switch Connector Terminal Identification
