Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Front Seat Switch Screw | 2 N.m | 18 lb in |
Fastener Tightening Specifications
Scheme 43
Scheme 43: Heated/Cooled Seat Schematics
Scheme 44
Scheme 45
Scheme 45: Heated/Cooled Seat Component Views
| Callout | Component Name |
|---|
| 1 | Heater Element Seat Back - Driver (KA1) |
| 2 | Lumbar Pump Motor - Driver (AG1) |
| 3 | Heater Element Seat Cushion - Driver (KA1) |
| 4 | S306 (AG1) |
| 5 | S312 (AG1) |
| 6 | Seat Circuit Breaker (AG1) |
| 7 | C307 (AG1) |
| 8 | C308 |
| 9 | Heated Seat Module - Driver (KA1) |
| 10 | Inflatable Restraint Seat Position Sensor (SPS) - Left |
| 11 | Seat Motors - Driver (AG1) |
| 12 | Seat Adjuster Switch - Driver (AG1) |
| 13 | Lumbar Adjuster/Heater Switch - Driver (AG1) |
| 14 | Seat Belt Buckle - Driver |
Scheme 46
| Callout | Component Name |
|---|
| 1 | Inflatable Restraint Passenger Presence System (PPS) Module |
| 2 | Heater Element Seat Cushion - Passenger (KA1) |
| 3 | Seat Belt Buckle - Passenger C1 |
| 4 | Seat Belt Buckle - Passenger C2 |
| 5 | C320 |
| 6 | C315 |
| 7 | C318 (AG2) |
| 8 | S341 (AG2) |
| 9 | S316 (AG2) |
| 10 | Inflatable Restraint Passenger Presence System (PPS) |
| 11 | Inflatable Restraint Seat Position Sensor (SPS) - Right |
| 12 | Lumbar Pump Motor - Passenger (AG2) |
| 13 | Heater Element Seat Back - Passenger (KA1) |
| 14 | Heated Seat Module - Passenger (KA1) |
| 15 | Seat Motors - Passenger (AG2) |
| 16 | Seat Belt Buckle - Passenger |
| 17 | Lumbar Adjuster/Heater Switch - Passenger (AG2) |
| 18 | Seat Adjuster Switch - Passenger (AG2) |
Scheme 47
Scheme 47: Lumbar Adjuster/Heater Switch - Driver (AG1)
| Connector Part Information OEM: 12045688 Service: 12101827 Description: 8-Way M Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Pins: A-C Terminal/Tray: 12059894/5 Core/Insulation Crimp: See Terminal Kit Release Tool/Test Probe: See Terminal Kit Pins: E-H Terminal/Tray: 12047581/2 Core/Insulation Crimp: E/A Release Tool/Test Probe: 12094429/J-35616-3 (GY) |
Driver Heated/Cooled Seat Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | BK | 2050 | Ground |
| B | PK | 1501 | Driver Heated Seat High/Low Signal |
| C | BN | 141 | Ignition 3 Voltage |
| D | | | Not Used |
| E | BK | 2050 | Ground |
| F | D-BU | 611 | Driver Seat Lumbar Motor Forward Control |
| G | PK | 610 | Driver Seat Lumbar Motor Rearward Control |
| H | OG | 1040 | Battery Positive Voltage |
Driver (AG1) Lumbar Adjuster/Heater Switch Connector Terminal Identification
