Fastener Tightening Specifications
| Application | Specification |
|---|
| Metric | English |
| Front Seat Belt Anchor Bolt | 52 N.m | 38 lb ft |
| Front Seat Belt Buckle Bolt | 52 N.m | 38 lb ft |
| Front Seat Belt Shoulder Adjuster Bolt | 52 N.m | 38 lb ft |
| Front Seat Belt Upper Guide Bolt | 52 N.m | 38 lb ft |
| Rear Center Seat Belt Bolt | 52 N.m | 38 lb ft |
| Rear Seat Belt Anchor Bolt | 52 N.m | 38 lb ft |
| Rear Seat Belt Retractor Bolt | 52 N.m | 38 lb ft |
| Rear Seat Belt Upper Guide Bolt | 52 N.m | 38 lb ft |
Fastener Tightening Specifications
Scheme 1
Scheme 1: Seat Belt Schematics
Scheme 2
Scheme 2: Seat Belt Component Views
| Callout | Component Name |
|---|
| 1 | Heater Element Seat Back - Driver (KA1) |
| 2 | Lumbar Pump Motor - Driver (AG1) |
| 3 | Heater Element Seat Cushion - Driver (KA1) |
| 4 | S306 (AG1) |
| 5 | S312 (AG1) |
| 6 | Seat Circuit Breaker (AG1) |
| 7 | C307 (AG1) |
| 8 | C308 |
| 9 | Heated Seat Module - Driver (KA1) |
| 10 | Inflatable Restraint Seat Position Sensor (SPS) - Left |
| 11 | Seat Motors - Driver (AG1) |
| 12 | Seat Adjuster Switch - Driver (AG1) |
| 13 | Lumbar Adjuster/Heater Switch - Driver (AG1) |
| 14 | Seat Belt Buckle - Driver |
Scheme 3
| Callout | Component Name |
|---|
| 1 | Inflatable Restraint Passenger Presence System (PPS) Module |
| 2 | Heater Element Seat Cushion - Passenger (KA1) |
| 3 | Seat Belt Buckle - Passenger C1 |
| 4 | Seat Belt Buckle - Passenger C2 |
| 5 | C320 |
| 6 | C315 |
| 7 | C318 (AG2) |
| 8 | S341 (AG2) |
| 9 | S316 (AG2) |
| 10 | Inflatable Restraint Passenger Presence System (PPS) |
| 11 | Inflatable Restraint Seat Position Sensor (SPS) - Right |
| 12 | Lumbar Pump Motor - Passenger (AG2) |
| 13 | Heater Element Seat Back - Passenger (KA1) |
| 14 | Heated Seat Module - Passenger (KA1) |
| 15 | Seat Motors - Passenger (AG2) |
| 16 | Seat Belt Buckle - Passenger |
| 17 | Lumbar Adjuster/Heater Switch - Passenger (AG2) |
| 18 | Seat Adjuster Switch - Passenger (AG2) |
Scheme 4
Scheme 4: Seat Belt Connector End View
| Connector Part Information OEM: 12047663 Service: 12085481 Description: 2-Way M Metri-Pack 150 Series (BK) |
|---|
| Terminal Part Information Terminal/Tray: 12047581/2 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12094429/J-35616-3 (GY) |
Driver Seat Belt Connector Parts Information
| Pin | Wire Color | Circuit No. | Function |
|---|
| A | BK/WH | 2151 | Ground |
| B | BK/WH | 2484 | Seat Belt Switch - Left |
Driver Seat Belt Buckle Connector Terminal Identification
