Power Outlets: Overview Hummer H3 I

Body Electrical 3 illustrations

Scheme 1

Scheme 1: Cigar Lighter/Power Outlet Schematics
Scheme 1: Cigar Lighter/Power Outlet Schematics

Scheme 2

Scheme 2: Power Outlet Component Views
Scheme 2: Power Outlet Component Views
CalloutComponent Name
1Auxiliary Power Outlets - Front
2Right Rear Side Panel
3Auxiliary Power Outlet - Rear

Scheme 3

Scheme 3: Auxiliary Power Outlet - Front 1
Scheme 3: Auxiliary Power Outlet - Front 1
Connector Part Information OEM: 12176836 Service: 15305923 Description: 3-Way F Metri-Pack 280 Series Flex Lock (GY)
Terminal Part Information Terminal/Tray: 12129424/4 Core/Insulation Crimp: See Terminal Kit Release Tool/Test Probe: See Terminal Kit

Power Outlet Connector Parts Information

PinWire ColorCircuit No.Function
AOG40Battery Positive Voltage
OG40Battery Positive Voltage
BNot Used
CBK2050Ground

Auxiliary Power Outlet Terminal Identification - Front 1
