Lighting: Specifications Hummer H2 I рестайлинг

Exterior Lights 17 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Bracket Bolts15 N.m11 lb ft
Clearance Lamp Screw3 N.m26 lb in
Cross Bar Assembly Locking Knobs7 N.m62 lb in
DRL Lamp Nuts6 N.m53 lb in
Front Marker Lamp Screws3 N.m26 lb in
Headlamp Nuts6 N.m53 lb in
High Mounted Stop Lamp Screws3 N.m26 lb in
Lamp Bar Assembly Locking Knobs7 N.m62 lb in
Lens Cover Screw2.5 N.m22 lb in
License Lamp Screws3 N.m26 lb in
License Plate Pocket Nuts - SUV6 N.m53 lb in
License Plate Spare Wheel Cover Nut - SUT6 N.m53 lb in
Park/Turn Lamp Nuts6 N.m53 lb in
Plastic Cover Screws5 N.m44 lb in
Rear Marker Lamp Screws3 N.m26 lb in
Rear Tail/Turn Lamp Screws6 N.m53 lb in

Scheme 1

Scheme 1: Headlights/Daytime Running Lights (DRL) Schematics
Scheme 1: Headlights/Daytime Running Lights (DRL) Schematics

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3: Exterior Lights Schematics
Scheme 3: Exterior Lights Schematics

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11: Interior Lights Schematics
Scheme 11: Interior Lights Schematics

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14: Interior Lights Dimming Schematics
Scheme 14: Interior Lights Dimming Schematics

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17
