Front Suspension System: Specifications Hummer H2 I

Suspension Front 2 illustrations ~238 words

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Brake Hose Bracket Bolt9 N.m80 lb in
Brake Hose Clip Bolts12 N.m106 lb in
Hub and Bearing Assembly to Steering Knuckle Bolts180 N.m133 lb ft
Jounce Bumper Stud Nut30 N.m22 lb ft
Lower Control Arm Ball Joint Stud Nut100 N.m74 lb ft
Lower Control Arm to Frame Nuts175 N.m129 lb ft
Sensor Wheel Speed Mounting Bolt18 N.m13 lb ft
Shock Absorber Tennon Nut20 N.m15 lb ft
Shock Absorber to Lower Control Arm Nut80 N.m59 lb ft
Stabilizer Shaft Insulator Clamp Bolts50 N.m37 lb ft
Stabilizer Shaft Link Nuts14 N.m10 lb ft
Torsion Bar Support Mounting Nuts110 N.m81 lb ft
Upper Control Arm Ball Joint Stud Nut50 N.m37 lb ft
Upper Control Arm to Frame Nuts190 N.m140 lb ft
Wheel Drive Shaft Nut235 N.m173 lb ft

Fastener Tightening Specifications

Scheme 4

Scheme 4: Removal Procedure
  1. Raise and support the vehicle. Refer to «Lifting and Jacking the Vehicle»(ref-187252-S32674187102005083100000) in General Information.
  2. Remove the nuts from the link bolt assemblies.
  3. Remove the link bolts.
  4. Remove the link assemblies.
  5. Remove the engine protection shield. Refer to «Engine Protection Shield Replacement»(ref-187245-S20847574952005083100000) .
  6. Remove the insulator clamp bolts.
  7. Remove the clamps.
  8. Remove the stabilizer shaft.
  9. Remove the insulators.
  10. Inspect all of the parts for wear and damage.

Scheme 5

Scheme 5: Installation Procedure
  1. Place the insulators on the stabilizer shaft with the slits facing toward the front of the vehicle.
  2. Install the insulators to the stabilizer shaft.
  3. Install the stabilizer shaft.
  4. Install the clamps over the insulators and the stabilizer shaft.
  5. Install insulator clamp bolts. Tighten: Tighten the bolts to 50 N.m (37 lb ft).
  6. Support the lower control arms at curb height.
  7. Perform the following procedure before installing the bolts. Remove all traces of the original adhesive patch. Clean the threads of the bolt with denatured alcohol or equivalent and allow to dry. Apply Threadlocker GM P/N 12345382 (Canadian P/N 10953489).
  8. Install the link assemblies.
  9. Install the link bolts.
  10. Install the nuts to the link bolt assemblies. Tighten: Tighten the nut to 14 N.m (10 lb ft).
  11. Ensure that the threads of the link bolt protrude 2 to 4 threads above the link nut.
  12. Install the engine protections shield. Refer to «Engine Protection Shield Replacement»(ref-187245-S20847574952005083100000) .
  13. Lower the vehicle.
