CHANGE OIL SOON INDICATOR RESET - PROCEDURE 1
- Turn the ignition key to RUN position, with engine off.
- Fully press and release the accelerator pedal slowly 3 times within 5 seconds. If the OIL LIFE RESET message flashes for 10 seconds, the system is resetting.
- Turn the key to LOCK position. If the CHANGE ENGINE OIL message comes back on when engine is started, repeat reset procedure.
CHANGE OIL SOON INDICATOR RESET - PROCEDURE 2
- Turn ignition on, with engine off. Press the fuel information button until ENGINE OIL LIFE appears on the screen.
- Press and hold the select button for 5 seconds.
- OIL LIFE RESET will appear on the screen for 10 seconds.
- The oil life system is reset. Turn ignition off.
Scheme 1
CHANGE OIL SOON INDICATOR RESET - PROCEDURE 3
| CAUTION | This vehicle has a computer system that indicates when to change the engine oil and filter. This is based on engine revolutions and engine temperature, and not on mileage. Based on driving conditions, the mileage at which an oil change is indicated can vary considerably. For the oil life system to work properly, the system must be reset every time the oil is changed. If the system is ever reset accidentally , the oil must be changed at 5 000 km (3,000 miles) since the last oil change. Remember to reset the oil life system whenever the oil is changed. |
- Turn the ignition key to ON/RUN with the engine off.
- Press and release the stem in the lower center of the instrument cluster until the OIL LIFE message is displayed.
- Once the alternating OIL LIFE and RESET messages appear, press and hold the stem until several beeps sound. This confirms that the oil life system has been reset.
- Turn the key to LOCK/OFF.
Note. If the CHANGE OIL message comes on again and stays on for 30 seconds at the next ignition cycle, it did not reset. The system needs to be reset again.
TPMS RESET - PROCEDURE 2
Note. When the wheels have been rotated, or a tire pressure sensor has been replaced, retrain tire pressure sensor.
Note. Learn Mode Cancellation: The learn mode will cancel if the ignition is cycled to OFF or if more than 2 minutes has elapsed for any sensor that has not been learned. If the learn mode is cancelled before the first sensor is learned, the original sensor IDs will be maintained. If the learn mode is canceled for any reason after the first sensor is learned, all IDs are erased from the BCM memory and if equipped, the DIC will display dashes for tire pressures.
| WARNING | Stray signals from other TPM equipped vehicles just driving by can be inadvertently learned. If any random horn chirps are heard from the vehicle while performing the learn procedure, most likely a stray sensor has been learned and the procedure will need to be cancelled and repeated. Under these circumstances, performing the TPM Learn Procedure away from other vehicles would be highly recommended. In the event a particular sensor activation does not cause the horn to chirp, it may be necessary to rotate the wheel valve stem to a different position due to the sensor signal is being blocked by another component. Before proceeding with the steps below, verify the following: No other sensor learn procedure is being performed simultaneously within close proximity. Tire pressures are not being adjusted on another TPM equipped vehicle within close proximity. Park Brake and Headlamp Switch input parameters are functioning correctly. |
- Turn ON the ignition, with the engine OFF.
- Apply the parking brake.
- Turn the exterior lamp switch from OFF to parking lamps 4 times within 4 seconds. A horn chirp will sound and the low tire pressure indicator will begin to flash indicating the learn mode has been enabled.
- Starting with the Left Front tire, learn the tire pressure using one of the following methods: Method 1: Hold the antenna of the tool against the tire sidewall close to the wheel rim at the valve stem location then press and release the activate button and wait for a horn chirp. Method 2: Increase/decrease the tire pressure for 8-10 seconds then wait for a horn chirp. The horn chirp may occur before or up to 30 seconds after the 8-10 second pressure increase/decrease time period has been reached. WARNING: Over inflating tires may cause personal injury or damage to the tires and wheels. When increasing tire pressure do not exceed the maximum inflation pressure as noted on the tire sidewall.
- After the horn chirp has sounded, repeat step 4 for the remaining 3 sensors in the following order: Right Front, Right Rear, Left Rear.
- After the LR sensor has been learned, a horn chirp will sound indicating all sensors have been learned.
- Turn OFF the ignition to exit the learn mode.
- After the learn mode has been exited, adjust all tires to the recommended pressures.
