General Information: Component Locations Hummer H2 I

Hoist/jack 8 illustrations ~497 words

Special Tools Ordering Information

The special service tools shown in this service manual that have product numbers beginning with J, SA or BT are available for worldwide distribution from

OE Tool and Equipment Group

Kent-Moore

28635 Mound Road

Warren

MI, U.S.A

48092-3499

Phone: 1-800-345-2233 or 586-574-2332

Monday through Friday

8:00 am-7:00 pm Eastern Standard Time

Fax: 1-800-578-7375 or 586-578-7321

The TECH 2 scan tool and accessories can be purchased through

Dealer Equipment and Services

5775 Enterprise Dr.

Warren

MI, U.S.A

48092-3463

Phone: 1-800-GM-TOOLS or 586-574-2332

Monday through Friday

8:00 am-6:00 pm EST

Fax: 1-586-578-7205

Engine ID and VIN Derivative Location

The eighth character in the Vehicle Identification Number (VIN) identifies the engine. Adhesive-backed labels attached to the engine, laser etching or stampings on the engine block indicate the engine unit number/date code. All engines are stamped with a VIN derivative.

Scheme 2

Scheme 2: Engine ID and VIN Derivative Location
CalloutComponent Name
1Primary Engine Identification Location
2Secondary Engine Identification Location

Transmission ID and VIN Derivative Location

A Transmission ID Tag and a VIN Derivation stamp is located on the transmission case.

Scheme 3

Scheme 3: Transmission ID and VIN Derivative Location

The 4L60-E transmission ID and VIN derivative location (1).

Scheme 4

Scheme 4: Transfer Case Identification

An identification tag is attached to the front half of the transfer case. The tag provides the following information

  1. Model number (1)
  2. Manufacturer (2)
  3. Part Number (3)
  4. Serial Number (4)

The information on this tag is necessary for servicing the transfer case. If the tag is removed or becomes dislodged during service operations, keep the identification tag with the unit.

Scheme 5

Scheme 5: Axle Identification - Front

Front axle identification information is stamped on the top of the differential carrier assembly. The information includes the following

  1. Broadcast code (1)
  2. Supplier code (2)
  3. Date built (3)
  4. Shift built (4) - Optional for 8.25 and 9.25 inch axles
  5. Hour built (5)

In order to verify reports made on the differential case assembly, include full code letters and build date numbers.

Scheme 6

Scheme 6: 8.6, 9.5, 10.5, 11.5

Rear axle identification information is stamped on the right side axle tube near the differential housing. The information includes the following

  1. Broadcast code (1)
  2. Build Source (2)
  3. Build date (3) - Julian date
  4. Shift built (4)

In order to verify reports made on the rear axle assembly, include full code letters and build date numbers.

Scheme 7

Scheme 7: Labeling - Anti-Theft

Federal law requires that General Motors label certain body parts on this vehicle with the vehicle identification number (VIN). The purpose of the law is to reduce the number of motor vehicle thefts by helping in the tracing and the recovery of parts from stolen vehicles.

The labels are permanently affixed to an interior surface of the part. The label on a replacement part contains the letter R, the manufacturer's logo, and the DOT symbol.

Scheme 8

Scheme 8: Label - Service Parts ID
CalloutComponent Name
1Vehicle Identification Number
2Wheel Base
3Part Number Location
4Model Designation
5Order Number
6Exterior Color
7Paint Technology

The service parts identification label is placed on the vehicle in order to help the service and parts personnel identify the vehicle's original parts and the vehicle's original options. The service parts identification label is located in the instrument panel (I/P) compartment.

Special Tools

Special Tools Tool Illustration Tool Number/Description J 41340 Ignition Lock Holding Fixture

Scheme 9

Scheme 9: Special Tools
