Entertainment Schematic Icons
Entertainment Schematic Icons Icon Icon Definition CAUTION: This vehicle is equipped with a Supplemental Inflatable Restraint (SIR) System. Failure to follow the correct procedure could cause the following conditions: Air bag deployment Personal injury Unnecessary SIR system repairs In order to avoid the above conditions, observe the following guidelines: Refer to SIR Component Views in order to determine if you are performing service on or near the SIR components or the SIR wiring. If you are performing service on or near the SIR components or the SIR wiring, disable the SIR system. Refer to Disabling the SIR System in SIR. IMPORTANT: Twisted-pair wires provide an effective "shield" that helps protect sensitive electronic components from electrical interference. If the wires were covered with shielding, install new shielding. In order to prevent electrical interference from degrading the performance of the connected components, you must maintain the proper specification when making any repairs to the twisted-pair wires shown : The wires must be twisted a minimum of 9 turns per 31 cm (12 in) as measured anywhere along the length of the wires. The outside diameter of the twisted wires must not exceed 6.0 mm (0.2 in)
Scheme 7
Scheme 8
Scheme 9
Scheme 10
Scheme 11
Scheme 12
Scheme 13
Scheme 14
Scheme 15
Scheme 16
| Callout | Component Name |
|---|---|
| 1 | Cellular and Navigation Antenna |
| 2 | Navigation Radio Antenna (UM8) |
| 3 | Radio w/DVD |
| 4 | Speaker - Front Subwoofer |
| 5 | Audio Amplifier |
| 6 | Rear Seat Audio (RSA) Controller |
Scheme 17
| Callout | Component Name |
|---|---|
| 1 | Garage Door Opener |
| 2 | Overhead Console |
| 3 | Speaker - LR Door |
| 4 | Windshield Side Garnish Molding |
| 5 | Speaker - Left A Pillar Tweeter Connector |
| 6 | Steering Wheel Controls |
Scheme 18
| Callout | Component Name |
|---|---|
| 1 | Cellular and Navigational Antenna |
| 2 | Radio Antenna |
| 3 | Global Positioning System (GPS) Antenna (I/P) |
Test Description
The numbers below refer to the step numbers on the diagnostic table.
- 2: Lack of communication may be due to a partial malfunction of the class 2 serial data circuit or due to a total malfunction of the class 2 serial data circuit. The specified procedure will determine the particular condition.First design uses a class 2 amplifier, 2nd design uses a non-class 2 amplifier.
- 5: The presence of DTCs which begin with "U" indicate some other module is not communicating. The specified procedure will compile all the available information before tests are performed.
| Step | Action | Yes | No |
|---|---|---|---|
| 1 | Install a scan tool. Turn ON the ignition, with the engine OFF. Does the scan tool power up? | Go to Step 2 | Go to Scan Tool Does Not Power Up in Data Link Communications |
| 2 | Attempt to establish communication with the following: Radio Amplifier (1st design only), refer to Radio/Audio System Description and Operation for explanation of designs. Body control module (BCM) Auxiliary HVAC control module Digital Radio Receiver (DRR) Does the scan tool communicate with the radio, amplifier, BCM, auxiliary HVAC control module, and DRR? | Go to Step 3 | Go to Scan Tool Does Not Communicate with Class 2 Device in Data Link Communications |
| 3 | IMPORTANT: The engine may start during the following step. Turn OFF the engine as soon as you have observed the Crank power mode. Access the Class 2 Power Mode in the Diagnostic Circuit Check on the scan tool. Rotate the ignition switch through all positions while observing the ignition switch power mode parameter. Does the ignition switch parameter reading match the ignition switch position for all switch positions? | Go to Step 4 | Go to Power Mode Mismatch in Body Control System |
| 4 | Select the following display DTCs function on the scan tool: Radio Amplifier (1st design only) Body control module (BCM) Auxiliary HVAC control module Digital Radio Receiver (DRR) Does the scan tool display any DTCs? | Go to Step 5 | Go to Symptoms - Entertainment |
| 5 | Does the scan tool display any DTCs which begin with a "U"? | Go to Scan Tool Does Not Communicate with Class 2 Device in Data Link Communications | Go to Step 6 |
| 6 | Does the scan tool display DTC B1000? | Go to Diagnostic Trouble Code (DTC) List in Body Control System | Go to Step 7 |
| 7 | Does the scan tool display DTC B1327? | Go to Diagnostic Trouble Code (DTC) List in Engine Electrical | Go to Diagnostic Trouble Code (DTC) List |
| IMPORTANT |
|---|
| The engine may start during the following step. Turn OFF the engine as soon as you have observed the Crank power mode. |
Diagnostic System Check - Entertainment System
The numbers below refer to the step numbers on the diagnostic table.
- 2: This step verifies that the DTC is still present.
- 3: This step isolates the fault condition.
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: Radio/Audio System Schematics (non Class 2 Amplifier) or Radio/Audio System Schematics (Class 2 Amplifier) | |||
| 1 | Did you perform the Diagnostic System Check - Entertainment System? | Go to Step 2 | Go to Diagnostic System Check - Entertainment System |
| 2 | Install a scan tool. Turn ON the ignition, with the engine OFF. With the scan tool, monitor the DTC Information for DTC B1025, B1035, B1045 OR B1055. Does the scan tool indicate that DTC B1025, B1035, B1045 OR B1055 is current? | Go to Step 3 | Go to Testing for Intermittent Conditions and Poor Connections in Wiring Systems |
| 3 | Test the speaker outputs from the radio for short to ground or voltage. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 6 | Go to Step 4 |
| 4 | Inspect for poor connections at the harness connector of the radio. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 6 | Go to Step 5 |
| 5 | IMPORTANT: Reprogram the radio. Refer to Service Programming System (SPS) in Programming. Replace the radio. Refer to Radio Replacement .Did you complete the replacement? | Go to Step 6 | |
| 6 | Operate the system in order to verify the repair. Did you correct the condition? | System OK | Go to Step 2 |
| IMPORTANT |
|---|
| Reprogram the radio. Refer to Service Programming System (SPS) in Programming. |
DTC B1025, B1035, B1045, or B1055
The numbers below refer to the step numbers on the diagnostic table.
- 2: This step helps to determine if the Diversity Antenna System is operating.
- 3: This step helps to determine if Radio Antenna Module is receiving the proper signal from the radio.
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: Radio/Audio System Schematics (non Class 2 Amplifier) or Radio/Audio System Schematics (Class 2 Amplifier) | |||
| 1 | Did you perform the Diagnostic System Check - Entertainment System? | Go to Step 2 | Go to Diagnostic System Check - Entertainment System |
| 2 | Turn ON the ignition, with the engine OFF. Turn ON the radio. Press the scan button. Do the local AM/FM stations come in clearly? | Go to Testing for Intermittent Conditions and Poor Connections in Wiring Systems | Go to Step 3 |
| 3 | Remove the radio. Test the Antenna Enable/Amplifier On Signal Circuit for a short or open. Did you locate and correct the condition? | Go to Step 4 | Go to Testing for Intermittent Conditions and Poor Connections in Wiring Systems |
| 4 | Operate the system in order to verify the repair. Did you complete the repair? | System OK | |
DTC B1235
The number below refers to the step number on the diagnostic table.
- 3: Tests for the proper operation of the circuit in the low voltage range.
| Step | Action | Value(s) | Yes | No |
|---|---|---|---|---|
| Schematic Reference: Radio/Audio System Schematics (non Class 2 Amplifier) or Radio/Audio System Schematics (Class 2 Amplifier) Connector End View Reference: Entertainment Connector End Views | ||||
| 1 | Did you perform the Diagnostic System Check - Entertainment System? | Go to Step 2 | Go to Diagnostic System Check - Entertainment System | |
| 2 | Install a scan tool. Turn ON the ignition, with the engine OFF. With a scan tool, observe the SWC Switch Voltage parameter in the Body Control Module data list. Does the scan tool indicate that the SWC Switch Voltage parameter is near the specified value? | 0 V | Go to Testing for Intermittent Conditions and Poor Connections in Wiring Systems | Go to Step 3 |
| 3 | CAUTION: Refer to SIR Caution in Cautions and Notices. Disable the SIR system. Refer to SIR Disabling and Enabling Zone 1 and SIR Disabling and Enabling Zone 3 in SIR. Turn OFF the ignition. Disconnect the left steering wheel controls. Turn ON the ignition, with the engine OFF. With a scan tool, observe the SWC Switch Voltage parameter. Does the scan tool indicate that the SWC Switch Voltage parameter is near the specified value? | 0 V | Go to Step 6 | Go to Step 4 |
| 4 | Turn OFF the ignition. Disconnect the right steering wheel controls. Turn ON the ignition, with the engine OFF. With a scan tool, observe the SWC Switch Voltage parameter. Does the scan tool indicate that the SWC Switch Voltage parameter is near the specified value? | 0 V | Go to Step 7 | Go to Step 5 |
| 5 | Test the remote radio control signal circuit for a short to voltage. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 12 | Go to Step 8 | |
| 6 | Inspect for poor connections at the harness connector of the left steering wheel control switch. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 12 | Go to Step 9 | |
| 7 | Inspect for poor connections at the harness connector of the right steering wheel control switch. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 12 | Go to Step 10 | |
| 8 | Inspect for poor connections at the harness connector of the body control module. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 12 | Go to Step 11 | |
| 9 | Replace the left steering wheel control switch. Refer to Steering Wheel Control Switch Assembly Replacement in Steering Wheel and Column. Did you complete the replacement? | Go to Step 12 | ||
| 10 | Replace the right steering wheel control switch. Refer to Steering Wheel Control Switch Assembly Replacement in Steering Wheel and Column. Did you complete the replacement? | Go to Step 12 | ||
| 11 | IMPORTANT: Perform the set up procedure for the body control module. Replace the body control module. Refer to Body Control Module Replacement in Body Control System.Did you complete the replacement? | Go to Step 12 | ||
| 12 | Enable the SIR system. Refer to SIR Disabling and Enabling Zone 1 and SIR Disabling and Enabling Zone 3 in SIR. Use the scan tool in order to clear the DTCs. Operate the vehicle within the Conditions for Running the DTC as specified in the supporting text. Does the DTC reset? | Go to Step 2 | System OK | |
| CAUTION |
|---|
| Refer to SIR Caution in Cautions and Notices. |
| IMPORTANT |
|---|
| Perform the set up procedure for the body control module. |
DTC B2815
Symptoms - Entertainment
| IMPORTANT | Perform the Diagnostic System Check - Entertainment System before using the Symptom Tables in order to verify that all of the following are true: There are no DTCs set. The control modules can communicate via the serial data link. Review the system operation in order to familiarize yourself with the system functions. Refer to Radio/Audio System Description and Operation . |
Radio/Audio System Description and Operation
The Entertainment System on this vehicle is configured with a radio, antenna, and speakers.
The following list shows the radios available for this vehicle
- Radio (UB1) - AM/FM, Cassette and CD
- Radio (UC6) - AM/FM, Integral Multi Disc CD Changer
- Navigation Radio (UM8)- AM/FM, CD, Navigation
| Controls | All Radios | ||
|---|---|---|---|
| Power | Push PWR/PUSH/VOL knob to turn the radio on. | ||
| Volume | The volume is adjusted by rotating the PWR/PUSH/VOL knob. | ||
| Automatic Volume Control | Press the AUTOVOL Button | ||
| Tune | Turn the TUNE/SELECT/PUSH RCL knob | ||
| Seek | Momentarily press SEEK/SCAN button | ||
| Scan | Hold SEEK/SCAN button at least 4 seconds | ||
| Presets | Six AM, Six FM1 and Six FM2 | ||
| Preset Saving | Press and hold desired button until an audible beep is heard | ||
| Set Clock | Press and hold the HR or MN button until an audible beep indicates the time set mode has been entered. Once the beep is heard, the time can be set by tapping each button to incrementally adjust the time. Holding down each button will rapidly change the time. | ||
| Recall | Push the TUNE/SELECT/PUSH RCL knob | ||
| Fade or Balance | Press BAL/FADE button to select and adjust w/SELECT knob | ||
| Bass, Treble or Midrange | Press TONE button to select and adjust w/SELECT knob | ||
| Automatic Tone | Press AUTO TONE Button | ||
Radio Features
| Controls | UB1 Radio |
|---|---|
| Eject | EJECT button |
| Fast Forward | Preset button 1 |
| Reverse | Preset button 4 |
| Auto Reverse | Yes |
| Side | Preset button 5 |
| Previous | Preset button 1 |
| Next | Preset button 2 |
| Dolby | Preset button 6 |
| Repeat | NA |
Cassette Features
| Controls | UB1 Radio | UC6 Radio |
|---|---|---|
| Eject | EJECT button | |
| Fast Forward | Preset button 1 | |
| Reverse | Preset button 4 | |
| Disc | Preset button 5 | |
| Previous | Preset button 1 | |
| Next | Preset button 2 | |
| Dolby | Preset button 6 | |
| Repeat | NA | |
| Random | Preset button 6 | |
Compact Disc Features
Each item in the list below represents topics covered in detail below.
- AM/FM Reception
- Voice Recorder (Travel Note)
- Audio Amplifier
- Theft Deterrent
- Integral Multi Disc CD Changer (IMDX)
- Remote Playback Device
- Radio Data System (RDS)
- Tape/CD Player Error Messages
- Rear Seat Audio (RSA)
- XM Satellite Radio
