Fastener Tightening Specifications
| Application | Specification | |
|---|---|---|
| Metric | English | |
| Yoke Retainer Bolts | 25 N.m | 18 lb ft |
Fastener Tightening Specifications
Scheme 1
| Callout | Component Name |
|---|---|
| 1 | Propeller Shaft Universal Joint |
| 2 | Propeller Shaft Tube |
| 3 | Propeller Shaft Universal Joint |
| 4 | Propeller Shaft Slip Yoke |
| 5 | Propeller Shaft Rear Slip Yoke Boot Clamp - Front |
| 6 | Propeller Shaft Rear Slip Yoke Boot |
| 7 | Propeller Shaft Rear Slip Yoke Boot Clamp - Rear |
Scheme 2
| Callout | Component Name |
|---|---|
| 1 | Propeller Shaft Slip Yoke |
| 2 | Propeller Shaft Universal Joint Spider Bearing Retainer Ring |
| 3 | Propeller Shaft Universal Joint |
| 4 | Propeller Shaft Tube |
| 5 | Propeller Shaft Universal Joint Spider Bearing Retainer Ring |
| 6 | Propeller Shaft Universal Joint |
| 7 | Propeller Shaft Bearing Retainer |
| 8 | Propeller Shaft Bearing Retainer Bolt |
Begin the system diagnosis by reviewing the system Description and Operation. Reviewing the Description and Operation information will help you determine the correct symptom diagnostic procedure when a malfunction exists. Reviewing the Description and Operation information will also help you determine if the condition described by the customer is normal operation. Refer to Symptoms - Propeller Shaft in order to identify the correct procedure for diagnosing the system and where the procedure is located.
Before beginning diagnosis, review the system description and operation in order to familiarize yourself with the system function. Refer to Propeller Shaft Description and Operation .
