Design Specifications
| Item | Measurement | Qualification | Specification |
|---|---|---|---|
| DIMENSIONS | Overall length | 2000-2007 | 4,115 mm (162.0 in.) |
| 2008-2009 | 4,135 mm (162.8 in.) | ||
| Overall width | 1,750 mm (68.9 in.) | ||
| Overall height | 1,285 mm (50.6 in.) | ||
| Wheelbase | 2,400 mm (94.5 in.) | ||
| Track | Front | 1,470 mm (57.9 in.) | |
| Rear 2000-2007 | 1,508 mm (59.4 in.) | ||
| Rear 2008-2009 | 1,510 mm (59.5 in.) | ||
| Ground clearance | 130 mm (5.1 in.) | ||
| Seating capacity | Two | ||
| WEIGHT | Gross Vehicle Weight Rating (GVWR) | 2000-2003 models | 1,535 kg (3,385 lbs) |
| 2004-2009 models | 1,550 kg (3,418 lbs) | ||
| ENGINE | Type | Water-cooled, 4-stroke DOHC VTEC gasoline engine | |
| Cylinder arrangement | Inline 4-cylinder, longitudinal | ||
| Bore and stroke | 2000-2003 models | 87.0 x 84.0 mm (3.43 x 3.31 in.) | |
| 2004-2009 models | 87.0 x 90.7 mm (3.43 x 3.57 in.) | ||
| Displacement | 2000-2003 models | 1,997 cm 3 (mL) (121.9 cu in.) | |
| 2004-2009 models | 2,157 cm 3 (mL) (131.6 cu in.) | ||
| Compression ratio | 11.0 | ||
| Valve train | Chain driven, DOHC VTEC 4 valves per cylinder | ||
| Lubrication system | Forced, wet sump, with trochoid pump | ||
| Oil pump displacement | At 6,000 RPM | 58.4 L (61.7 US qt)/minute | |
| Water pump displacement | At 6,000 RPM | 172 L (182 US qt)/minute | |
| Fuel required | Premium UNLEADED gasoline with 91 Pump Octane Number or higher | ||
| STARTER | Type | Gear reduction | |
| Normal output | 2000-2003 models | 1.0 kW | |
| 2004-2009 models | 1.1 kW | ||
| Nominal voltage | 12 V | ||
| Hour rating | 30 seconds | ||
| Direction of rotation | Clockwise as viewed from gear end | ||
| CLUTCH | Clutch | Single plate dry, diaphragm spring | |
| Clutch friction material surface area | 188 cm 2 (29 sq in.) | ||
| MANUAL TRANSMISSION | Type | Synchronized 6-speed forward, 1 reverse | |
| Primary reduction | 2000-2003 models | Direct 1:1 | |
| 2004-2009 models | 1 208 | ||
| Gear ratio | 1st | 3.133 | |
| 2nd | 2.045 | ||
| 3rd | 1.481 | ||
| 4th | 1.161 | ||
| 5th 2000-2003 models | 0.979 | ||
| 5th 2004-2008 models | 0.943 | ||
| 6th 2000-2003 models | 0.810 | ||
| 2004-2009 models | 0.763 | ||
| Reverse | 2.800 | ||
| Secondary reduction gear | Type | Single helical gear | |
| Gear ratio 2000-2003 models | 1.160 | ||
| Gear ratio 2004-2009 models | 1.208 | ||
| DIFFERENTIAL | Final reduction gear | Type | Spiral bevel gear |
| Gear ratio | 4.100 | ||
| STEERING | Type | Electrical, power-assisted rack and pinion | |
| Overall ratio | 13.9 | ||
| Turns, lock-to-lock | 2.4 | ||
| Steering wheel diameter | 360 mm (14.1 in.) | ||
| SUSPENSION | Type | Front | Independent double wishbone, coil spring with stabilizer |
| Rear | Independent double wishbone, coil spring with stabilizer | ||
| Shock absorber | Front and rear | Telescopic, hydraulic, nitrogen gas-filled | |
| TIRES | Size of front and rear tires (2000-03 models) | Front | 205/55R16 89W |
| Rear | 225/50R16 92W | ||
| Size of front and rear tires (2004-07 models) | Front | 215/45R17 97W | |
| Rear | 245/40R17 91W | ||
| Size of front and rear tires (2008-09 models) | Front | 215/45R17 97W | |
| Rear (except CR) | 245/40R17 91W | ||
| Rear (CR) | 255/40R17 94W | ||
| Size of spare tire | T125/70D16 96M | ||
| WHEEL ALIGNMENT | Camber | Front | 0° 30' |
| Rear | 1° 30' | ||
| Caster | Front | 6° 00' | |
| Total Toe-in (2000-03 models) | Front | 0 mm (0 in.) | |
| Rear | 6 mm (0.24 in.) | ||
| Total Toe-in (2004-2009 models) | Rear (except CR) | 3.6 mm (0.14 in.) | |
| Rear (CR) | 5.5 mm (0.22 in.) | ||
| BRAKES | Type of service brake | Front | Power-assisted self-adjusting ventilated disc |
| Rear | Power-assisted self-adjusting solid disc | ||
| Type of parking brake | Mechanical actuating, rear wheels | ||
| Pad friction surface area | Front | 42 cm 2 (6.5 sq in.) x 2 | |
| Rear | 28 cm 2 (4.3 sq in.) x 2 | ||
| AIR CONDITIONING | Cooling capacity | 3,320 Kcal/h (13,170 BTU/h) | |
| Compressor | Type/Manufacturer | Scroll/KEIHIN | |
| Number of cylinders | |||
| Capacity | 85.7 mL (5.23 cu in.)/rev. | ||
| Maximum speed | 12,000 RPM | ||
| Lubricant capacity | 130 mL (4 1/3 fl oz) | ||
| Lubricant type | KEIHIN SP-10 | ||
| Condenser | Type | Corrugated fin | |
| Evaporator | Type | Corrugated fin | |
| Blower | Type | Sirocco fan | |
| Motor input | 220 W/12 V | ||
| Speed control | 7-speed manual A/C | ||
| Maximum capacity | 430 m 3 /h (15,200 cu ft/h) | ||
| Temperature control | Air-mix type | ||
| Refrigerant | Type | HFC-134a (R-134a) | |
| Quantity | 600-650 g (21.2-22.9 oz) | ||
| ELECTRICAL RATINGS | Battery | 12 V-36 AH/5 hours | |
| Fuses | Main underhood fuse/relay box | 100 A, 40 A, 30 A, 20 A, 15 A, 10 A | |
| Auxiliary underhood fuse box | 70 A, 60 A, 20 A | ||
| Under-dash fuse/relay box | 20 A, 15 A, 10 A, 7.5 A | ||
| Light bulbs | Headlight high beam | 12 V-55 W (HI) | |
| Headlight low beam | 12 V-35 W (HID) | ||
| Front turn signal lights | 12 V-21 W | ||
| Front parking lights 2000-2003 models | 12 V-5 W | ||
| Front parking/side marker lights 2004-2009 models | 12 V-5 W | ||
| Rear turn signal lights | 12 V-21 W | ||
| Rear side marker lights 2000-2003 models | 12 V-5 W | ||
| Rear side marker lights 2004-2009 models | LED | ||
| Side turn signal lights | 12 V-5 W | ||
| Brake/Taillights 2000-2003 models | 12 V-21/5 W | ||
| Brake/Taillights 2004-2009 models | LED | ||
| High-mount brake light | LED | ||
| Back-up lights | 12 V-21 W | ||
| License plate light | 12 V-5 W | ||
| Trunk light | 12 V-5 W | ||
| Ceiling light/Spotlights | 12 V-5 W | ||
| Gauge lights | 12 V-3 W, 2 W | ||
| Indicator lights | 12 V-1.12 W, 1.4 W | ||
| Panel and pilot lights | 12 V - 0.56 W, 0.84 W, 0.91 W, LED |
