Valve Clearance Adjustment
Note. Adjust the valves only when the cylinder head temperature is less than 100 °F (38 °C).
Scheme 47
Scheme 48
Scheme 49
Scheme 50
Scheme 51
Scheme 52
Scheme 53
- Remove the cylinder head cover (see «CYLINDER HEAD COVER REMOVAL»(ref-221322-S15452678522006022400000) ).
- Set the No. 1 piston at top dead center (TDC). The TDC marks (A) on the cam chain sprocket should align with the cylinder head surface.
- Select the correct thickness feeler gauge for the valves you're going to check. Intake: 0.21-0.25 mm (0.008-0.010 in.) Exhaust: 0.25-0.29 mm (0.010-0.011 in.) Adjusting screw location
- Insert the feeler gauge (A) between the adjusting screw and the end of the valve stem and slide it back and forth; you should feel a slight amount of drag.
- If you feel too much or too little drag, loosen the locknut (A), and turn the adjusting screw (B) until the drag on the feeler gauge is correct.
- Tighten the locknut and recheck the clearance. Repeat the adjustment, if necessary.
- Rotate the crankshaft 180 ° clockwise (camshaft gears turn 90 °)
- Check and, if necessary, adjust the valve clearance on No. 3 cylinder.
- Rotate the crankshaft 180 ° clockwise (camshaft gears turn 90°)
- Check and, if necessary, adjust the valve clearance on No. 4 cylinder.
- Rotate the crankshaft 180 ° clockwise (camshaft gears turn 90°)
- Check and, if necessary, adjust the valve clearance on No. 2 cylinder.
- Install the cylinder head cover (see «CYLINDER HEAD COVER INSTALLATION»(ref-221322-S09112251732006022400000) ).
