Power Steering System: Component Locations Honda S2000 AP1

Special Tools Required

Locknut wrench, 43 mm 07MAA-SL0020A

Scheme 22

Scheme 23

1. Set the wheels in the straight ahead position.
2. Remove the splash shield.
3. Remove the lower radiator hose bracket (A).
4. Loosen the rack guide screw locknut (A) with the special tool, then loosen the rack guide screw (B).
5. Tighten the rack guide screw to 25 N.m (2.5 kgf.m, 18 lbf.ft), then loosen it.
6. Retighten the rack guide screw to 3.9 N.m (0.4 kgf.m, 2.9 lbf.ft) then back it off to the specified angle. Specified return angle: 10 to 20 °
7. Tighten the locknut to 25 N.m (2.5 kgf.m, 18 lbf.ft) while holding the rack guide screw.
8. Install the lower radiator hose bracket.
9. Install the splash shield.
10. Check for tight or loose steering from lock to lock.
11. Perform following inspections: Steering wheel rotational play (see «STEERING WHEEL ROTATIONAL PLAY CHECK»(ref-221352-S34302340352006022400000) ). Power assist with vehicle parked (see «STEERING WHEEL ROTATIONAL PLAY CHECK»(ref-221352-S34302340352006022400000) ).
