Interior Lights Honda S2000 AP1

Scheme 1

Scheme 2

Scheme 3

Scheme 4

1. Turn the ceiling/spotlights switch OFF.
2. Pry off the lens (A). Ceiling Light/Spotlight Bulb: 5 W
3. Remove the two screws and the ceiling/spotlight housing.
4. Disconnect the 4P connector (B) from the housing (C).
5. Check for continuity between the terminals in each switch position according to the table below.
6. If the continuity is not as specified, replace the bulbs or the light.

Scheme 5

1. Open the trunk lid.
2. Pry out the trunk light assembly. Trunk Light Bulb: 5W
3. Disconnect the 2P connector from the housing.
4. Open the trunk light cover.
5. Check for continuity between the No. 1 and No. 2 terminals.
6. If there is no continuity, replace the bulb or the light.

Scheme 6

Scheme 7

1. Open the trunk lid.
2. Disconnect the 3P connector from the trunk lid latch.
3. Check for continuity between the terminals in each trunk lid position according to the table below.
4. If the continuity is not as specified, replace the trunk lid latch.
