DTC P0102: MAF Sensor Circuit Low Voltage Honda Ridgeline I рестайлинг

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 65

Scheme 66

Scheme 67

Scheme 68

1. Turn the ignition switch to ON (II), and wait 2 seconds.
2. Check the MAF SENSOR in the DATA LIST with the HDS. Is about 0 gm/s, or 0.1 V or less indicated? YES -Go to step 3. NO -Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the MAF sensor and the PCM.
3. Turn the ignition switch to LOCK (0).
4. Disconnect the MAF sensor/IAT sensor 5P connector.
5. Turn the ignition switch to ON (II).
6. Measure the voltage between MAF sensor/IAT sensor 5P connector terminal No. 5 and body ground. Is there battery voltage? YES -Go to step 7. NO -Repair open in the wire between PGM-FI main relay 1 and the MAF sensor, then Go to step 19 .
7. Turn the ignition switch to LOCK (0).
8. Measure the resistance between MAF sensor/IAT sensor 5P connector terminal No. 3 and body ground. Is there 190-210 kohms? YES -Go to step 13 . NO -Go to step 9.
9. Jump the SCS line with the HDS.
10. Disconnect PCM connector A (49P).
11. Check for continuity between PCM connector terminal A20 and body ground. Is there continuity? YES -Repair short in the wire between the PCM (A20) and the MAF sensor, then Go to step 20 . NO -Go to step 12.
12. Check for continuity between PCM connector terminal A20 and MAF sensor/IAT sensor 5P connector terminal No. 3. Is there continuity? YES -Go to step 25 . NO -Repair open in the wire between the PCM (A20) and the MAF sensor, then Go to step 20 .
13. Substitute a known-good MAF sensor/I AT sensor (see «MAF SENSOR/IAT SENSOR REPLACEMENT»(ref-336453-S25816260512009072700000) ).
14. Reconnect all connectors.
15. Turn the ignition switch to ON (II).
16. Clear the DTC with the HDS.
17. Start the engine. Hold the engine speed at 2,000 rpm without load (in P or N).
18. Check for Pending DTCs or Confirmed DTCs with the HDS. Is DTC P0102 indicated? YES -Reinstall the original MAF sensor/IAT sensor, and Go to step 26 . NO -Replace the original MAF sensor/IAT sensor (see «MAF SENSOR/IAT SENSOR REPLACEMENT»(ref-336453-S25816260512009072700000) ), then Go to step 19.
19. Turn the ignition switch to LOCK (0).
20. Reconnect all connectors.
21. Turn the ignition switch to ON (II).
22. Reset the PCM with the HDS.
23. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(ref-336473-S09468920992009072700000) ).
24. Check for Pending DTCs or Confirmed DTCs with the HDS. Is DTC P0102 indicated? YES -Check for poor connections or loose terminals at the MAF sensor/IAT sensor and the PCM, then Go to step 1 . NO -Troubleshooting is complete. If any other Pending DTCs or Confirmed DTCs are indicated, Go to the indicated DTC's troubleshooting.
25. Reconnect all connectors.
26. Update the PCM if it does not have the latest software (see «PCM UPDATE»(ref-336453-S09500398002009072700000) ), or substitute a known-good PCM (see «SUBSTITUTING THE PCM»(ref-336452-S17145915352009072700000) ).
27. Check for Pending DTCs or Confirmed DTCs with the HDS. Is DTC P0102 indicated? YES -Check for poor connections or loose terminals at the MAF sensor/IAT sensor and the PCM. If the PCM was updated, substitute a known-good PCM (see «SUBSTITUTING THE PCM»(ref-336452-S17145915352009072700000) ), then recheck. If the PCM was substituted, Go to step 1. NO -If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(ref-336453-S28620960052009072700000) ). If any other Pending DTCs or Confirmed DTCs are indicated, Go to the indicated DTC's troubleshooting.
