Auxiliary Under-Hood Relay Box
| Socket | Ref | Terminal | Connects to |
|---|
| A/C condenser fan relay | 4 | 4 | Right engine compartment wire harness (see RIGHT ENGINE COMPARTMENT WIRE HARNESS ) |
| Fan control relay | 3 | 5 | Right engine compartment wire harness (see RIGHT ENGINE COMPARTMENT WIRE HARNESS ) |
| Fog light relay (1) | 2 | 4 | Right engine compartment wire harness (see RIGHT ENGINE COMPARTMENT WIRE HARNESS ) |
| Radiator fan relay | 1 | 4 | Right engine compartment wire harness (see RIGHT ENGINE COMPARTMENT WIRE HARNESS ) |
| (1) RTL and EX-L models |
TERMINAL AND SOCKET REFERENCE CHART
Scheme 65
Auxiliary Under-Hood Fuse Box
| Socket | Ref | Terminal | Connects to |
|---|
| T5 | 1 | | Starter cable (see CONNECTOR TO HARNESS INDEX ) |
TERMINAL AND SOCKET REFERENCE CHART
Scheme 66
