DTC P0451: FTP Sensor Range/Performance; Problem Honda Ridgeline I

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ). If DTC P2422 is stored at the same time as DTC P0451, troubleshoot DTC P2422 first, then recheck for DTC P0451.

1. Turn the ignition switch ON (II).
2. Clear the DTC with the HDS.
3. Start the engine, and let it idle 1 minute.
4. Monitor the OBD STATUS for DTC P0451 in the DTCs MENU with the HDS. Does the screen indicate FAILED? YES - Go to step 5. NO - If the screen indicates PASSED, intermittent failure, system is OK at this time. Check for poor connections or loose terminals at the FTP sensor and the PCM. If the screen indicates NOT COMPLETED, go to step 3 and recheck.
5. Turn the ignition switch OFF.
6. Replace the FTP sensor (see «FTP SENSOR REPLACEMENT»(ref-219966-S27399276402006021600000) ).
7. Turn the ignition switch ON (II).
8. Reset the PCM with the HDS.
9. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(ref-219960-S21279730262006021600000) ).
10. Start the engine, and let it idle 1 minute.
11. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0451 indicated? YES - Check for poor connections or loose terminals at the FTP sensor and the PCM, then go to step 1 . NO - Go to step 12.
12. Monitor the OBD STATUS for DTC P0451 in the DTCs MENU with the HDS. Does the screen indicate PASSED? YES - Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated in step 11, go to the indicated DTCs troubleshooting. NO - If the screen indicates FAILED, check for poor connections or loose terminals at the FTP sensor and the PCM, then go to step 1 . If the screen indicates NOT COMPLETED, go to step 10 and recheck.

Scheme 30

Scheme 31

Scheme 32

Scheme 33

1. Turn the ignition switch ON (II).
2. Clear the DTC with the HDS.
3. Turn the ignition switch OFF.
4. Remove the fuel fill cap.
5. Turn the ignition switch ON (II).
6. Check the FTP SENSOR in the DATA LIST with the HDS. Is about - 7.3 kPa (-2.16 in.Hg, - 55 mmHg), or 0.3 V or less indicated? YES - Go to step 10 . NO - Go to step 7.
7. Install the fuel fill cap.
8. Start the engine.
9. Monitor the OBD STATUS for DTC P0452 in the DTCs MENU with the HDS. Does the screen indicate FAILED? YES - Go to step 10. NO - If the screen indicates PASSED, intermittent failure, system is OK at this time. Check for poor connections or loose terminals at the FTP sensor and the PCM. If the screen indicates NOT COMPLETED, go to step 5 and recheck.
10. Turn the ignition switch OFF.
11. Disconnect the FTP sensor 3P connector.
12. Turn the ignition switch ON (II).
13. Check the FTP SENSOR in the DATA LIST with the HDS. Is about 7.3 kPa (2.15 in.Hg, 54.7 mmHg), or 4.90 V indicated? YES - Go to step 24 . NO - Go to step 14.
14. Measure voltage between FTP sensor 3P connector terminal No. 1 and body ground. Is there about 5 V? YES - Go to step 20 . NO - Go to step 15.
15. Turn the ignition switch OFF.
16. Jump the SCS line with the HDS.
17. Disconnect PCM connector A (44P).
18. Connect FTP sensor 3P connector terminal No. 1 to body ground with a jumper wire.
19. Check for continuity between PCM connector terminal A19 and body ground. Is there continuity? YES - Go to step 32 . NO - Repair open in the wire between the PCM (A19) and the FTP sensor, then go to step 26 .
20. Turn the ignition switch OFF.
21. Jump the SCS line with the HDS.
22. Disconnect PCM connector A (44P).
23. Check for continuity between FTP sensor 3P connector terminal No. 2 and body ground. Is there continuity? YES - Repair short in the wire between the PCM (A33) and the FTP sensor, then go to step 26 . NO - Go to step 32 .
24. Turn the ignition switch OFF.
25. Replace the FTP sensor (see «FTP SENSOR REPLACEMENT»(ref-219966-S27399276402006021600000) ).
26. Reconnect all connectors.
27. Turn the ignition switch ON (II).
28. Reset the PCM with the HDS.
29. Do the PCM idle learn procedure (see «PCM IDLE LEARN PROCEDURE»(ref-219960-S21279730262006021600000) ).
30. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0452 indicated? YES - Check for poor connections or loose terminals at the FTP sensor and the PCM, then go to step 1 . NO - Go to step 31.
31. Monitor the OBD STATUS for DTC P0452 in the DTCs MENU with the HDS. Does the screen indicate PASSED? YES - Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated in step 30, go to the indicated DTCs troubleshooting. NO - If the screen indicates FAILED, check for poor connections or loose terminals at the FTP sensor and the PCM, then go to step 1 . If the screen indicates NOT COMPLETED, keep idling until a result comes on.
32. Reconnect all connectors.
33. Update the PCM if it does not have the latest software, or substitute a known-good PCM (see «PCM UPDATING AND SUBSTITUTION FOR TESTING»(ref-219956-S29187290912006021600000) ). If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.
34. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0452 indicated? YES - Check for poor connections or loose terminals at the FTP sensor and the PCM. If the PCM was updated, substitute a known-good PCM (see ), then recheck. If the PCM was substituted, go to step 1 . NO - Go to step 34
35. Monitor the OBD STATUS for DTC P0452 in the DTCs MENU with the HDS. Does the screen indicate PASSED? YES - If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the original PCM (see «PCM REPLACEMENT»(ref-299652-S28764766372008092500000) ). If any other Temporary DTCs or DTCs were indicated in step 34, go to the indicated DTC's troubleshooting. NO - If the screen indicates FAILED, check for poor connections or loose terminals at the FTP sensor and the PCM. If the PCM was updated, substitute a known-good PCM (see «PCM UPDATING AND SUBSTITUTION FOR TESTING»(ref-219956-S29187290912006021600000) ), then recheck. If the PCM was updated, go to step 1 and recheck. If the screen indicates NOT COMPLETED, keep idling until a result comes on.
