Climate Control: Overview Honda Ridgeline I

Automatic HVAC System 5 illustrations ~383 words

Scheme 1

Scheme 1: Component Location Index
Scheme 1: Component Location Index

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4: How to Check for DTCs with the HDS
Scheme 4: How to Check for DTCs with the HDS
  1. Make sure the ignition switch is OFF.
  2. Connect the HDS to the data link connector (DLC) (A) located under the driver's side of the dashboard.
  3. Turn the ignition switch ON (II).
  4. Make sure the HDS communicates with the vehicle and the climate control unit. If it doesn't, troubleshoot the DLC circuit (see «DLC CIRCUIT TROUBLESHOOTING»(ref-299652-S32992582592008092500000) ).
  5. Select HVAC/CLIMATE CONTROL in the BODY ELECTRICAL menu.
  6. Select DTCs in the HVAC/CLIMATE CONTROL menu.
  7. Check for DTCs. If any DTCs are indicated, write down the DTCs, then go to the indicated DTC troubleshooting. If no DTCs are indicated, refer to symptom troubleshooting. NOTE: After troubleshooting, clear the DTCs with the HDS. For specific operations, refer to the user's manual that came with the HDS.

System Description

The air conditioning system removes heat from the passenger compartment by transferring heat from the ambient air to the evaporator. The evaporator cools the air with the refrigerant that is circulating through the evaporator. The refrigerant expands in the evaporator, and the evaporator becomes very cold and absorbs the heat from the ambient air. The blower fan pushes air across the evaporator where the heat is absorbed, and then it blows the cool air into the passenger compartment.

Scheme 5

Scheme 5: System Description
Scheme 5: System Description

This vehicle uses HFC-134a (R-134a) refrigerant, which does not contain chlorofluorocarbons. Pay attention to the following service items

  1. Do not mix refrigerants CFC-12 (R-12) and HFC-134a (R-134a). They are not compatible.
  2. Use only the recommended polyalkyleneglycol (PAG) refrigerant oil (DENSO ND-OIL 8) designed for the R-134a A/C compressor. Intermixing the recommended (PAG) refrigerant oil with any other refrigerant oil will result in A/C compressor failure.
  3. All A/C system parts (A/C compressor, discharge line, suction line, evaporator, A/C condenser, receiver/dryer, expansion valve, O-rings for joints) are designed for refrigerant R-134a. Do not exchange with R-12 parts.
  4. Use a halogen gas leak detector designed for refrigerant R-134a.
  5. R-12 and R-134a refrigerant servicing equipment are not interchangeable. Use only a recovery/recycling/charging station that is U.L.-listed and is certified to meet the requirements of SAE J2210 to service the R-134a air conditioning systems.
  6. Always recover refrigerant R-134a with an approved recovery/recycling/charging station before disconnecting any A/C fitting.
