Wiring diagram: Air conditioning — Heater circuit Honda Prelude V
All systems — 28 systems
- Air conditioning 2
- Anti-lock brakes
- Anti-theft 2
- Body computer
- Computer data lines
- Cooling fan
- Cruise control
- Defoggers 2
- Engine performance 2.2l
- Exterior lights 2
- Ground distribution
- Headlights 2
- Horn
- Instrument cluster
- Interior lights 3
- Power distribution
- Power door locks
- Power mirrors 2
- Power seats
- Power top/sunroof
- Power windows
- Radio
- Shift interlocks
- Starting/charging 2
- Supplemental restraints
- Transmission 2
- Warning systems
- Wiper/washer
Components on these wiring diagrams 23
Click a component to highlight it on every diagram it appears on.
