SERVICE VALVE LOCATIONS
| Vehicle | High | Low |
|---|---|---|
| Accord | (1) | (3) |
| Civic | (4) | (4) |
| CR-V | (5) | (2) |
| Odyssey | (4) | (4) |
| Passport | (6) | (7) |
| Prelude | (1) | (2) |
| (1) On high pressure line, near receiver-drier. (2) On low pressure line, near top of condenser. (3) On low pressure line, between evaporator and compressor. (4) On top of condenser, on right side. (5) On high pressure outlet at compressor. On Honda CR-V (Scheme 6) (6) On high pressure (thin) line, at rear of engine compartment. (Scheme 7) (7) On low pressure (thick) line, at rear of engine compartment. | ||
| (1) | On high pressure line, near receiver-drier. |
| (2) | On low pressure line, near top of condenser. |
| (3) | On low pressure line, between evaporator and compressor. |
| (4) | On top of condenser, on right side. |
| (5) | On high pressure outlet at compressor. On Honda CR-V (Scheme 6) |
| (6) | On high pressure (thin) line, at rear of engine compartment. (Scheme 7) |
| (7) | On low pressure (thick) line, at rear of engine compartment. |
SERVICE VALVE LOCATIONS
